Tool for fretboard/string radius?

Discussion in 'Hardware, Setup & Repair [BG]' started by rollyolly, Nov 22, 2012.


  1. rollyolly

    rollyolly

    Joined:
    Nov 10, 2011
    Is there an inexpensive tool for placing on my strings to adjust the saddle heights to be the same as the neck radius?

  2. Rip Topaz

    Rip Topaz

    Joined:
    Aug 12, 2005
    Location:
    Willow Street, PA
    Disclosures:
    Beta tester for Positive Grid
  3. Steveaux

    Steveaux

    Joined:
    Jul 1, 2008
    Location:
    The Wilds of NW Pa.
    Yup.

    [​IMG]

  4. JLS

    JLS Supporting Member

    Joined:
    Sep 12, 2008
    Location:
    Emeryville, Ca
    Disclosures:
    I setup & repair guitars & basses
    Your eyes. This is not rocket science.

  5. Register to disable this ad
  6. SoVeryTired

    SoVeryTired Endorsing nothing, recommending much Supporting Member

    Joined:
    Jul 2, 2011
    Location:
    Milton Keynes, UK
  7. Stilettoprefer

    Stilettoprefer

    Joined:
    Nov 26, 2010
    Your strings will naturally follow the radius of the board If you set it up well. I've never used a radius gauge for anything more than figuring out what radius a fingerboard was so that I could get a sanding block to copy it.

  8. walterw

    walterw Supportive Fender Gold Supporting Member

    Joined:
    Feb 20, 2009
    this.

    instead, use:
    measure from the bottom of each string to the top of a certain fret (for me it's the 15th); get them all the same distance and you'll automatically have a perfect radius, one that takes into account how the string spread starts out narrow at the nut and ends up wide at the bridge.

    you might want to have the high strings a little lower, in which case you get your heights for the smallest and biggest strings, then set each string in between gradually higher under there from the first to the last string.
