In excellent condition.
The Blue Soul is our first Class D amp. Like all other Glockenklang amps, it features a warm and dynamic sound up to full power. Two switchable inputs, switchable 5-band eq, switchable effects-loop, mp3-player input, symmetrical DI-out, tuner out and phones output are the main features.
High performance class D power amp section (650 watts / 4 0hms, 350 watts / 8 ohms)
intern (DIP-switches at bottom) switchable to 650 W / 2,7 ohm, 450 W / 4 ohm, 240 W / 8 ohm
Excellent equalization section, switchable
LED peak indicator for pre amp and power amp
LED indicators for all switch functions
Dual high impedance input A/B box with separate pre gain trim for input B
Effect Return also usable as mp3 player and additional mixing input
Balanced DI out, adjustable (on left side by screwdriver)
Tuner out
Phones out
Compact and robust design
Lighweight 5 kg (11 lbs)
Inputs:
Input A for instruments with normal level
Input B with additional pre gain trim control for instruments with higher level and for piezo pickups
Tone controls:
Switchable 5 band EQ
Bass +/- 15 dB
Low +/- 12 dB
Mid +/- 8 dB
High +/- 12 dB
Treble +/- 15 dB
Effect lopps
1parallel effects loop, post eq, intensity controlled by effects section on the
front panel, footswitchable, also usable as second, mixable input
Dimensions: 320 x 280 x 88 mm, 12.6" x 11" x 3.5" (2 rackspaces)
