Tube
Ruby 12AX7AC5 HG
Tone control
A channel : Passive Bass/Treble tonestack
B channel : Passive Bass/Treble tonestack – Active Mid/Sweep control – Gain : -18 to +6 dB – Freq : 220Hz à 1.5kHz
Input / Output
Input : Jack 6.35 mm unbalanced (TS, Tip/Sleeve) – Impedance : 1 MOhms
Return : Jack 6.35mm unbalanced (TS) – Max input level : 17 dBu – Impedance : 2,2 MOhms – Unbuffered, directly connected to Output when active
Output : Jack 6.35 mm unbalanced (TS) – Max output level : 11 dBu – Impedance : 300 Ohms
Thru : Jack 6.35 mm unbalanced (TS) – Unbuffered, directly connected to Inpu
Send : Jack 6.35 mm unbalanced (TS) – Max output level : 11 dBu – Impedance : 300 Ohms
DI Output : XLR, balanced – Impedance : 600 Ohms – Max output level : 10 dBu
Phones : Jack 3.5 mm stereo (TRS, Tip/Ring/Sleeve)
Power
Mains power adaptor DC Jack 2.1mm, negative center
Input voltage : 12V DC
Power consumption : approx. 6W
Current draw : 500mA
Dimensions & weight
Width x depth x height: 124 x 189 x 50 (mm) – 4.88 x 7.44 x 1.97 (in)
Weight : 750g – 1.65 lb
