List of widths at nut.

#221
RedVee said:
@JACink
I'm just questioning the Epiphone (bolt on) Thunderbird IV @ 1.75" - aren't they 1.73", the same as the Goth Bird? Except for dome special editions at 1.5".

I know 0.02" isn't much :) but it may as well be right. Were older ones 1.75" ?
Click to expand...

To be totally honest, I have no idea as I don't have one to measure, but the Epiphone website says that you are correct ;)

I will update the list to show 1.73", at least until someone chimes in with a real world measurement (if it is different).

Thanks @RedVee

#222
Corrected Epiphone Thunderbird IV.

CURRENT LIST:

4 STRINGS
Alembic Classic: 1.75" (44.5mm)
Alembic Comfort: 1.625" (41.3mm)
Alembic Slender: 1.5" (38mm)
Alleva RA 4 string: 1.5" (38mm)
Andrew Drake "Wilma" - 1.653" (42mm)
Aria A-200 - 1.44" (36.6mm)
Aria Rock 'n' Roller 4001 - 1.59" (40.5mm)
Aria SB700 - 1.811" (46mm)
Aslin Dane Jazz Copy - 1.62" (41.3mm)
BC Rich Warlock Platinum Series - 1.65" (42mm)
Carvin LB70 - 1.54" (39.1mm)
Cort C4H (<2009) - 1.57" (40mm)
Cort C4H (>2010) - 1.5" (38mm)
Danelectro 63 RI (MIK) - 1.625" (41.3mm)
Dean USA Hillsboro - 1.5" (38mm)
Eastwood Classic 4 - 1.5" (38mm)
Eastwood HiFlyer - 1.86" (47mm)
EBMM Bongo 4 - 1.625" (41.3 mm)
EBMM Ray 34 - 1.69" (43mm)
EBMM Sig.4 - 1.5" (38mm)
EBMM Sterling - 1.5" (38mm)
EBMM Stingray - 1.625" (41.3mm)
EBMM StingRay (1995) - 1.69" (42.9mm)
EBMM Stingray SLO - 1.5" (38mm)
EPI LTD Explorer = 1.662" (42.2mm)
Epiphone EB-0 - 1.5" (38mm)
Epiphone Jack Casady Signature - 1.65" (42mm)
Epiphone Thunderbird IV - 1.73" (43.9mm)
Epiphone Thunderbird pro-IV - 1.5" (38mm)
Epiphone Thunderbird (all 4 strings) - 1.5" (38mm)
Epiphone Toby Deluxe IV - 1.68" (42.67mm)
Epiphone Toby STandard IV - 1.68" (42.67mm)
ESP B-4 - 1.57" (40mm)
ESP D-4 - 1.57" (40mm)
ESP LTD B-154DX - 1.57" (40mm)
ESP LTD B204SM - 1.57" (40mm)
ESP LTD B-4E - 1.65" (42mm)
ESP LTD EC-104 - 1.57" (40mm)
ESP LTD F-414FM - 1.65" (42mm)
ESP LTD FB-4 Frank Bello - 1.65" (42mm)
ESP LTD GC-4 - 1.57" (40mm)
ESP LTD PT-4 Pancho Tomaseli - 1.77" (45mm)
ESP LTD Vintage-204 - 1.65" (42mm)
Faith Titan Neptune ABG - 1.673" (42.5mm)
Fender 56 Precision - 1.73" (43.9mm)
Fender 59 Precision - 1.71" (43.5mm)
Fender 60 Classic Jazz - 1.5" (38mm)
Fender 62RI Jazz - 1.5" (38mm)
Fender 64 Jazz - 1.5" (38mm)
Fender 67 Precision - 1.625" (41mm)
Fender 68 Telecaster - 1.75" (44.5mm)
Fender 69 Telecaster - 1.81" (45.9mm)
Fender 70 Classic Jazz - 1.5" (38mm)
Fender 70s Precision - 1.62" (41.3mm)
Fender 73 Precision (B Neck) - 1.64" (41.7mm)
Fender 82 Fullerton 57 Precision RI - 1.78" (45.2mm)
Fender '82 MIA Bullet B30 - 1.625" (41.3mm)
Fender Aerodyne Jazz - 1.5" (38mm)
Fender American Deluxe Jazz - 1.5" (38mm)
Fender American Deluxe P-Bass - 1.62" (41.3mm)
Fender American Hot Rod Precision '99 - 1.644" (41.8mm)
Fender American Special Jazz - 1.5" (38mm)
Fender American Special P-Bass - 1.69" (43mm)
Fender American Standard (1st version) '88-'94 - 1.5" (38mm)
Fender Antigua Precision - 1.62" (41.3mm)
Fender AVRI '57 & '62 P-bass - 1.75" (44.5mm)
Fender BG29 Bass - 1,70" (43.2mm)
Fender Blacktop Jazz - 1.5" (38mm)
Fender Blacktop Precision - 1.62" (41.3mm)
Fender Cabronita Precision (MIM) = 1.65” (42mm)
Fender Coronado (New) - 1.625" (41.3 mm)
Fender Coronado (vintage) - 1.5" (38mm)
Fender Custom Shop '59 NOS P - 1.75" (44.5mm)
Fender Custom Shop '64 Jazz Bass (NOS) - 1.5" (38mm)
Fender Custom Shop Jazz - 1.5" (38mm)
Fender Dimension - 1.5625" (39.6mm)
Fender Duff McKagan P-Bass - 1.62" (41.3mm)
Fender FR 51 Resonator Bass - 1.69" (43mm)
Fender Geddy Lee Jazz Bass (CIJ) - 1.5" (38mm)
Fender Geddy Lee USA Jazz = 1.55" (39.4mm)
Fender HM - 1.5" (38mm)
Fender Jazz Bass (original) - 1.437" (36.5mm)
Fender Jazz Plus '90-'94 - 1.5" (38mm)
Fender Jazz Special (mid 80's MIJ) - 1.5" (38mm)
Fender Jazz Special (1987) - 1.528" (38.8mm)
Fender Japan PJM-65R "Jazz Special" (1985) - 1.515" (38.5mm)
Fender Kingman AB - 1.5" (38mm)
Fender Limited Geddy Lee 1972 Jazz - 1.5" (38mm)
Fender Limited Gold Top Dusty Hill Precision - 1.5" (38mm)
Fender Mark Hoppus Jazz - 1.62" (41.3mm)
Fender Mike Dirnt Road Worn Precision - 1.59" (40.4mm)
Fender Modern Player Dimension - 1.5" (38mm)
Fender Modern Player Jaguar - 1.5" (38mm)
Fender Modern Player Jazz - 1.5" (38mm)
Fender Modern Player Jazz Satin - 1.5" (38mm)
Fender Modern Player Tele Bass - 1.62" (41.3mm)
Fender Musicmaster Bass (1st version) - 1.625" (41.3mm)
Fender Musicmaster Bass 1976 - 1.59" (40.4mm)
Fender Mustang Bass RI MIJ 2006 - 1.5" (38mm)
Fender Precision Bass Special Deluxe Series - 1.5" (38mm)
Fender Precision Elite - 1.75" (44.5mm)
Fender Precision LYTE Deluxe - 1.50" (38mm)
Fender Reggie Hamilton Jazz - 1.5" (38mm)
Fender Road Worn 50 P-Bass - 1.75" (44.5mm)
Fender Roger Waters Precision - 1.75" (44.5mm)
Fender Sean Hurley Signature 1961 Precision - 1.75" (44.45mm)
Fender Select Jazz - 1.5" (38mm)
Fender Select Precision - 1.62" (41.3mm)
Fender Standard Jazz - 1.5" (38mm)
Fender Starcaster (New) - 1.625" (41.3mm)
Fender Steve Harris P-Bass - 1.75" (44.5mm)
Fender Telecaster Bass - 1.75" (44.5mm)
Fender Troy Sanders Jaguar - 1.5" (38mm)
Fender Vintage Hot Rod '60s Precision - 1.625" (41.3mm)
Fender Vintage Hot Rod '70s Jazz - 1.5" (38mm)
G&L 2012 Special M-2000 - 1.75" (44.5mm)
G&L Asat Semi Hollow - 1.5" (38mm)
G&L L1K '81 - 1.703" (43.3mm)
G&L L1000 2014 - 1.709" (43.4mm)
G&L L-2000 - 1.79" (45.5mm)
G&L SB-2T '14 (#7 neck) - 1.718" (43.6mm)
G&L Tribute L-2000 - 1.75" (44.5mm)
G&L Tribute L2000 (2012/13) - 1.692" (43mm)
G&L Tribute JB-2 - 1.5" (38mm)
G&L Tribute SB-2 - 1.5" (38mm)
Gibson EB-2 (vintage) - 1.60" (42mm)
Gibson EB-3 (1965) - 1.69" (43mm)
Gibson EB-3 (1973) - 1.562" (39.7mm)
Gibson Les Paul Oversized - 1.6" (40.6mm)
Gibson SG-Bass - 1.60" (42mm)
Godin Shifter Bass - 1.5" (38,1mm)
Gretsch G2202 Junior Jet - 1.625" (41.3mm)
Gretsch G5440LSB Electromatic - 1.69" (43mm)
Gretsch White Falcon - 1.28" (32.5mm)
Guild Starfire Reissue - 1.5" (38mm)
Harley Benton HBZ-2004 - 1.57" (40mm)
Harley Benton JB-20 Standard - 1.5" (38mm)
Harley Benton PB-20 - 1.65" (42mm)
Harley Benton PB-50 - 1.65" (42mm)
Harley Benton PJ-4 Deluxe - 1.65" (42mm)
Harmony (unknown model 1991) - 1.65" (42mm)
Herby Custom Bass (MIJ. Ric copy 60's/70's) - 1.662" (42.2mm)
Hohner HAB-50 PS ABG - 1.668" (42.4mm)
Höfner 182 - 1.808" (45.9mm)
Hofner 500/1 - 1.65" (42mm)
Hofner Shorty - 1.69" (43mm)
Hondo Longhorn 1181 - 1.5" (38mm)
Ibanez AEB10 - 1.687" (42.84mm)
Ibanez AGB140 - 1.533" (39.4mm)
Ibanez Artcore AGB-200 Shortscale (2011) – 1.65” (42mm)
Ibanez EXB404 - 1.56" (39.6mm)
Ibanez GATK20 (2010-2011) - 1.673" (42.5mm)
Ibanez GSR200fm - 1.5625" (39.7mm)
Ibanez GSRM20 Mikro Bass - 1.5" (38mm)
Ibanez Musician MC-924 (1980) – 1.65” (42mm)
Ibanez Musician MC-940 (1982) – 1.614” (41mm)
Ibanez Roadstar II RB-920 (1983) – 1.575” (40mm)
Ibanez Roadster RS-824 (1981) – 1.594” (40.5mm)
Ibanez Roadster RS-940 (1980) – 1.65” (42mm)
Ibanez SR300 (2010) - 1.5” (38mm)
Ibanez SR4 - 1.5" (38mm)
Ibanez SR500 (2009) - 1.437" (36.5mm)
Ibanez SR500 (2012 approx.) - 1.5" (38mm)
Ibanez SRA500/SRA550 - 1.5" (38mm)
Ibanez SR600 - 1.5" (38mm)
Jack & Danny Jazz Bass - 1.5" (38mm)
Jackson C20 - 1.625" (41.3mm)
Jolana Diamant (Zech. LP) - 1.789" (45.7mm)
Lakland 44-64 Custom - 1.5" (38mm)
Lakland Skyline 44-01 - 1.65" (42mm)
Lakland USA Duck Dunn - 1.5" (38mm)
Mighty mite Jazz replacement neck (maple fingerboard) - 1,5" (38mm)
Mighty mite Precision replacement neck (maple fingerboard) - 1.62" (41,3mm)
Mike Lull P4 w/Jazz neck - 1.5" (38mm)
MTD Kingston Heir - 1.56" (39.6mm)
OLP MM2 (3rd generation, I believe) - 1.69" (43mm)
Peavey Forum P/J (1994) - 1.5" (38.1mm)
Peavey Foundation (1986) - 1.5" (38.1mm)
Peavey Foundation (1991 & 1992) = 1.5" (38mm)
Peavey Fury (1983 - slanted SF) - 1.75" (44.5mm)
Peavey Fury (1987) = 1.5" (38mm)
Peavey Fury (1990 - P) - 1.5" (38.1mm)
Peavey Fury (1991 & 1992) = 1.5" (38mm)
Peavey Milestone III Jazz Bass - 1.5" (38mm)
Peavey Milestone IV P Bass - 1.46" (37mm)
Peavey Millenium BXP Jazz - 1.5" (38mm)
Peavey Patriot (1985) - 1.6875" (42.86mm)
Peavey Patriot (1987) = 1.5" (38mm)
Peavey RJ-IV (1991) - 1.6" (40.6mm)
Peavey Sarzo (US - 1991) - 1.625" (41.3mm)
Peavey T-20 (1982) - 1.6875" (42.86mm)
Peavey T-40 (1979) - 1.6875" (42.86mm)
Peavey Unity (1991 Koa P/J) - 1.6" (40.6mm)
PRS #11 - 1.692" (43mm)
Rickenbacker 4001 (1979) - 1.71" (43.5mm)
Rickenbacker 4001 (1979) - 1.69" (43mm)
Rickenbacker 4001 (March 1973) - 1.625" (41.3mm)
Rickenbacker 4001V63 (April 1998) - 1.718" (43.6mm)
Rickenbacker 4003FL (1985) - 1.625" (41.275mm)
Rickenbacker 4004 Laredo (NAMM Show instrument-December 2011) - 1.687" (42.8mm)
Rick Turner Renaissance RB4FL (2005-NAMM Show instrument) - 1.5" (38mm)
Rob Allen Mouse - 1.653" (42mm)
Roscoe Custom "Birdie" - 1.653" (42mm)
Roscoe Custom "Bucky" - 1.811" (46mm)
Sadowsky Metro RV4-WL - 1.45" (37mm)
Sadowsky NYC J4 - 1.5" (38mm)
Sadowsky NYC Will Lee - 1.45" (37mm)
Schecter Raiden Special 4 - 1.653” (42mm)
Schecter Stiletto Extreme 4 = 1.5" (38mm)
Sire M3 = 1.5" (38mm)
Spector Forte-4 - 1.61" (41mm)
Spector Legend 4 (1st Gen.) - 1.565" (39.75mm)
Spector Legend CLS - 1.5625" (39.7mm)
Spector Legend NS-2 - 1.5" (38mm)
Spector NS-2JA-R - 1.65" (42mm)
Squier Affinity Jazz - 1.5" (38mm)
Squier Affinity P-Bass - 1.62" (41.3mm)
Squier Bronco - 1.62" (41.3mm)
Squier Bronco (20th Anniversary Model) - 1.614" (41mm)
Squier Classic Vibe Jazz - 1.5" (38mm)
Squier Classic Vibe P-Bass 50 - 1.65" (42mm)
Squier Classic Vibe 60s P-Bass - 1.62" (41.3mm)
Squier Dimension - 1.57" (40mm)
Squier Jaguar Short Scale - 1.5" (38mm)
Squier Matt Freeman P-Bass - 1.65" (42mm)
Squier Mike Dirnt Precision - 1.65" (42mm)
Squier Mikey Way Mustang - 1.5" (38mm)
Squier Pro Tone Precision Bass - 1.5" (38mm)
Squier Troy Sanders Jaguar - 1.5" (38mm)
Squier Vintage Modified Cabronita Precision Bass - 1.625" (41.3mm)
Squier Vintage Modified Fretless Jazz - 1.5" (38mm)
Squier Vintage Modified Jaguar "Standard" - 1.5" (38mm)
Squier Vintage Modified Jazz - 1.5" (38mm)
Squier Vintage Modified Jazz '70S - 1.5" (38mm)
Squier Vintage Modified Jazz '77 - 1.5" (38mm)
Squier Vintage Modified Precision - 1.62" (41.1mm)
Squier Vintage Modified Precision Fretless - 1.625" (41.3mm)
Squier Vintage Modified Precision PJ - 1.625" (41.3mm)
Squier Vintage Modified Precision TB - 1.59" (40.5mm)
Squier Vintage Modified Telecaster - 1.732" (44mm)
Squier Vintage Modified Telecaster Bass IV - 1.7" (43.2 mm)
Steinberger XP2 '86 - 1.5" (38mm)
Sterling by Music Man Ray4 - 1.5" (38mm)
Sterling by Music Man SUB SB4 - 1.5" (38mm)
Stu Hamm Urge I (1985) - 1.614" (41mm)
Suhr Classic J - 1.5" (38mm)
SX SBG2 - 1.69" (43mm)
SX SWB1 - 1.5" (38mm)
SX Ursa 1 - 1.625" (42mm)
SX Ursa 1 - 1.687" (43mm)
Takamine B10 - 1.8125" (46mm)
Takamine EG512 - 1.6875" (43mm)
Traben Standard 4 - 1.5" (38mm)
Vantage VA-900B (1981) – 1.59” (40.5mm)
Vantage VA-900B/FL (1981) – 1.59” (40.5mm)
Viola Bass with Variax transplant - 1.712" 43.5mm
Wal Mk 1 Custom Series (Soft V Profile) - 1.625" (42mm)
Wal Pro Series (C Profile) - 1.6875" (43mm)
Warwick Alien - 1.535" (39mm)
Warwick Buzzard - 1.73" (44mm)
Warwick Corvette 4 = 1.5" (38mm)
Warwick Corvette 4 $$ = 1.5" (38mm)
Warwick Dolphin - 1.73" (44mm)
Warwick Rockbass COrvett Short Scale - 1.5" (38mm)
Warwick Streamer 4 = 1.5" (38mm)
Warwick Stryker - 1.73" (44mm)
Warwick "Other 4 Models" - 1.515" (38.5mm)
Warwick Thumb NT4 (2013) - 1.51" (38.4mm)
Washburn SHB40 = 1.65" (42mm)
Washburn T24 = 1.589" (40.4mm)
Yamaha Attitude Standard (1991) = 1.65” (42mm)
Yamaha BB404 - 1.5838" (40.48mm)
Yamaha BB Series (424 to 2024) - 1.57" (40mm)
Yamaha RBX170 = 1.57" (40mm)
Yamaha RBX300 (1990) - 1.57" (40mm)
Yamaha TRBX 504 - 1.5" (38mm)
Zon VB-4 (Vinny) - 1.532" (38.9mm)

5 STRINGS
Alembic Classic - 2.00" (50.8mm)
Alembic Comfort - 1.875" (47.6mm)
Carvin LB75 (1991) - 1.71" (43.5mm)
Conklin Groove Tools GT-5 - 1.751" (44.5mm)
Cort Action V - 1.77" (45mm)
Dean Sledgehammer 5 Ash – 1.75” (44.45mm)
EBMM Stingray 5 - 1.75" (44.45mm)
Epiphone Thunderbird (all 5 strings) 1.73" - (43.94mm)
ESP B55 - 1.692" (43mm)
ESP LTD B-1005 - 1.85" (47mm)
ESP LTD B-105 - 1.77" (45mm)
ESP LTD B-155DX - 1.77" (45mm)
ESP LTD B-335 - 1.77" (45mm)
ESP LTD B-5 JR Junior Black - 1.625" (41.3mm)
ESP LTD B205SM - 1.77" (45mm)
ESP D5 - 1.771" (45mm)
ESP LTD F-105 - 1.77" (45mm)
ESP LTD F-5E - 1.85" (47mm)
ESP Surveyor 5 - 1.5" (38mm)
Fender American Deluxe Jazz V - 1.875" (47.6mm)
Fender Am Std Dimension - 1.75" (44.45mm)
Fender Modern Player Jazz V Satin - 1.875" (47.6mm)
Fender Standard Jazz V - 1.85" (47mm)
G&L L-2500 - 1.75" (44.5mm)
G&L Tribute L-2500 - 1.75" (44.5mm)
Harley Benton B-500 Modern Series - 1.77" (45mm)
Harley Benton HBZ-2005 - 1.77" (45mm)
Harley Benton PJ-5 Deluxe - 1.77 "(45mm)
Ibanez ATK305 ? 1.75? (44.5mm)
Ibanez BTB 675 - 1.85" (47mm)
Ibanez EX (1994) - 1.76" (44.7mm)
Ibanez Gary Willis Signature GWB1 - 1.75" (44.5mm)
Ibanez Gary Willis Signature GWB2 - 1.75" (44.5mm)
Ibanez GSRM25 Mikro Bass 5 - 1.77" (45mm)
Ibanez Sr705 2014 - 1.693" (43mm)
Ibanez SR1205-VNF - 1.77" (45mm)
Ibanez SR5 - 1.77" (45mm)
Lakland 55-94 - 1.80" (45.7mm)
Lightwave Saber SL 5 (fretted) ? 1.75? (44.5mm)
Martin Keith Elfin 5 fretless (2010-NAMM Show instrument) - 1.875" (47.6mm)
Martin Keith Elfin 5 (2011) - 1.875" (47.6mm)
Modulus Bassstar - 1.75" (44.5mm)
Modulus Q5 - 1.85" (47mm)
Modulus Q5W19 - 1.90" (48.26mm)
Modulus Q5W21 - 2.00" (50.8mm)
MPG Level-5 Fretless - 1.81" (45.97mm)
Spector Coda-5DLX/XL - 1.87" (47.6mm)
Spector Coda Pro 5 - 1.75" (44.45mm)
Spector Core 5 - 1.75" (44.45mm)
Spector Euro5LX - 1.85" (46.99mm)
Spector Forte-5 - 1.81" (45.97mm)
Spector Legend Classic-5 - 1.75" (44.45mm)
Spector NS-5 - 1.80" (45.72mm)
Spector NS-5H2 (Wide-5 model) - 1.80" (45.72mm) or 1.88" (47.75mm)
Spector NS-5XL - 1.81" (45.97mm)
Spector Performer 5 - 1.75" (44.45mm)
Spector ReBop-5 - 1.81" (45.97mm)
Squier Affinity Jazz V - 1.87" (47.6mm)
Squier Deluxe Jazz V - 2" (51mm)
Squier Dimension - 1.75" (44.45mm)
Squier Standard P Bass Special 5 - 2.008" (51mm)
Squier Vintage Modified Jazz V - 1.87" (47.6mm)
Sterling by Music Man SUB - 1.77" (45mm)
Sterling by Music Man Ray5 - 1.77" (45mm)
Vintage Modified Precision V - 1.875" (47.6mm)
Steinberger Spirit 5 circa 2010, 1.75" (44.5mm)
Steinberger Synapse - 1.77" (44.96mm) @ 0 fret
Traben Array 5 - 1.78" (45.2mm)
Traben Array Limited - 1.78" (45.2mm)
Traben Chaos Core 5 - 1.78" (45.2mm)
Traben Standard 5 - 1.5" (38mm)
Wal 5-String Mark IIs - 1.85" (47mm)
Wal 5-String Mark IIIs - 1.85" (47mm)
Warwick "All 5 Models" - 1.771" (45mm) or 1.85" (47mm)
Yamaha BB1025 – 1.692” (43mm)
Yamaha BB415 - 1.653" (42mm)
Yamaha BBNE1/BBEAST - 1.875" (47.62mm)
Yamaha TRBX 505 - 1.692" (43mm)
Zon 5/1 (circa 1996) - 1.85" (47mm)

6 STRINGS
Brice Z6 – 2.126” (54mm)
Carvin LB76 - 2.02" (51.3mm)
Harley Benton HBB600TBK - 2.175" (55.2mm)
Harley Benton HBB6000 - 2.095" (53.2mm)
Ibanez BTB 456 – 2.126” (54mm)
Roscoe 3006 - 2.150" (54.61mm)
Squier Vintage Modified Bass VI - 1.65" (42mm)
Tune TWB63WN - 2.291" (58.2mm)
Warwick "All 6 Models" - 2.047" (52mm) or 2.165" (55mm)
Yamaha RBX6JM (2000 mk i) -1.968" 50mm
Yamaha TRB 6II – 2.047” (52mm)
Yamaha TRB JP2 – 2.205” (56mm)

7 STRINGS
Roscoe SKB 3007 - 2.470" (63.14mm)
Wolf WTHB-7W - 2.418" (61.4mm)
Zdressy Fretless (2016) - 2.36" (59.9mm)

8 STRINGS
Ibanez Musician MC-980 (1980) – 1.692” (43mm)

  • Like
Reactions: Plutonium244 and RedVee
#224
Jens Ritter has the Standard & Vintage spacing for all models (custom spacing is also possible)

STANDARD SPACING
4-String Standard Nut: 32mm (1.26")
5-String Standard Nut: 40mm (1.57")
6-String Standard Nut: 45mm (1.77")
7-String Standard Nut: 53mm (2.09")

VINTAGE SPACING
4-String Vintage Nut: 30mm (1.18")
5-String Vintage Nut: 38mm (1.50")
6-String Vintage Nut: 44mm (1.73")

Jens Ritter Website said:
Over several years of experience with different players, different in body height and different in playing style, I defined a standard string spacing for all my instruments. This spacing is progressive, increasing from the high to the low strings. ..
On my Bass Guitars the spacing is measured from outer edge to outer edge of each string. This is mathematically not correct, but you have a real better feeling and control while moving with the right hand from string to string.
Click to expand...

  • Like
Reactions: JACink
#225
ChrisDev said:
Jens Ritter has the Standard & Vintage spacing for all models (custom spacing is also possible)

STANDARD SPACING
4-String Standard Nut: 32mm (1.26")
5-String Standard Nut: 40mm (1.57")
6-String Standard Nut: 45mm (1.77")
7-String Standard Nut: 53mm (2.09")

VINTAGE SPACING
4-String Vintage Nut: 30mm (1.18")
5-String Vintage Nut: 38mm (1.50")
6-String Vintage Nut: 44mm (1.73")
Click to expand...

Thank you for thay, but the measurements are the actual spacing of the strings, not the width of the nut (or so I believe?)

#227
List updated, thank you @ChrisDev :thumbsup:

CURRENT LIST:

4 STRINGS
Alembic Classic: 1.75" (44.5mm)
Alembic Comfort: 1.625" (41.3mm)
Alembic Slender: 1.5" (38mm)
Alleva RA 4 string: 1.5" (38mm)
Andrew Drake "Wilma" - 1.653" (42mm)
Aria A-200 - 1.44" (36.6mm)
Aria Rock 'n' Roller 4001 - 1.59" (40.5mm)
Aria SB700 - 1.811" (46mm)
Aslin Dane Jazz Copy - 1.62" (41.3mm)
BC Rich Warlock Platinum Series - 1.65" (42mm)
Carvin LB70 - 1.54" (39.1mm)
Cort C4H (<2009) - 1.57" (40mm)
Cort C4H (>2010) - 1.5" (38mm)
Danelectro 63 RI (MIK) - 1.625" (41.3mm)
Dean USA Hillsboro - 1.5" (38mm)
Eastwood Classic 4 - 1.5" (38mm)
Eastwood HiFlyer - 1.86" (47mm)
EBMM Bongo 4 - 1.625" (41.3 mm)
EBMM Ray 34 - 1.69" (43mm)
EBMM Sig.4 - 1.5" (38mm)
EBMM Sterling - 1.5" (38mm)
EBMM Stingray - 1.625" (41.3mm)
EBMM StingRay (1995) - 1.69" (42.9mm)
EBMM Stingray SLO - 1.5" (38mm)
EPI LTD Explorer = 1.662" (42.2mm)
Epiphone EB-0 - 1.5" (38mm)
Epiphone Jack Casady Signature - 1.65" (42mm)
Epiphone Thunderbird IV - 1.73" (43.9mm)
Epiphone Thunderbird pro-IV - 1.5" (38mm)
Epiphone Thunderbird (all 4 strings) - 1.5" (38mm)
Epiphone Toby Deluxe IV - 1.68" (42.67mm)
Epiphone Toby STandard IV - 1.68" (42.67mm)
ESP B-4 - 1.57" (40mm)
ESP D-4 - 1.57" (40mm)
ESP LTD B-154DX - 1.57" (40mm)
ESP LTD B204SM - 1.57" (40mm)
ESP LTD B-4E - 1.65" (42mm)
ESP LTD EC-104 - 1.57" (40mm)
ESP LTD F-414FM - 1.65" (42mm)
ESP LTD FB-4 Frank Bello - 1.65" (42mm)
ESP LTD GC-4 - 1.57" (40mm)
ESP LTD PT-4 Pancho Tomaseli - 1.77" (45mm)
ESP LTD Vintage-204 - 1.65" (42mm)
Faith Titan Neptune ABG - 1.673" (42.5mm)
Fender 56 Precision - 1.73" (43.9mm)
Fender 59 Precision - 1.71" (43.5mm)
Fender 60 Classic Jazz - 1.5" (38mm)
Fender 62RI Jazz - 1.5" (38mm)
Fender 64 Jazz - 1.5" (38mm)
Fender 67 Precision - 1.625" (41mm)
Fender 68 Telecaster - 1.75" (44.5mm)
Fender 69 Telecaster - 1.81" (45.9mm)
Fender 70 Classic Jazz - 1.5" (38mm)
Fender 70s Precision - 1.62" (41.3mm)
Fender 73 Precision (B Neck) - 1.64" (41.7mm)
Fender 82 Fullerton 57 Precision RI - 1.78" (45.2mm)
Fender '82 MIA Bullet B30 - 1.625" (41.3mm)
Fender Aerodyne Jazz - 1.5" (38mm)
Fender American Deluxe Jazz - 1.5" (38mm)
Fender American Deluxe P-Bass - 1.62" (41.3mm)
Fender American Hot Rod Precision '99 - 1.644" (41.8mm)
Fender American Special Jazz - 1.5" (38mm)
Fender American Special P-Bass - 1.69" (43mm)
Fender American Standard (1st version) '88-'94 - 1.5" (38mm)
Fender Antigua Precision - 1.62" (41.3mm)
Fender AVRI '57 & '62 P-bass - 1.75" (44.5mm)
Fender BG29 Bass - 1,70" (43.2mm)
Fender Blacktop Jazz - 1.5" (38mm)
Fender Blacktop Precision - 1.62" (41.3mm)
Fender Cabronita Precision (MIM) = 1.65” (42mm)
Fender Coronado (New) - 1.625" (41.3 mm)
Fender Coronado (vintage) - 1.5" (38mm)
Fender Custom Shop '59 NOS P - 1.75" (44.5mm)
Fender Custom Shop '64 Jazz Bass (NOS) - 1.5" (38mm)
Fender Custom Shop Jazz - 1.5" (38mm)
Fender Dimension - 1.5625" (39.6mm)
Fender Duff McKagan P-Bass - 1.62" (41.3mm)
Fender FR 51 Resonator Bass - 1.69" (43mm)
Fender Geddy Lee Jazz Bass (CIJ) - 1.5" (38mm)
Fender Geddy Lee USA Jazz = 1.55" (39.4mm)
Fender HM - 1.5" (38mm)
Fender Jazz Bass (original) - 1.437" (36.5mm)
Fender Jazz Plus '90-'94 - 1.5" (38mm)
Fender Jazz Special (mid 80's MIJ) - 1.5" (38mm)
Fender Jazz Special (1987) - 1.528" (38.8mm)
Fender Japan PJM-65R "Jazz Special" (1985) - 1.515" (38.5mm)
Fender Kingman AB - 1.5" (38mm)
Fender Limited Geddy Lee 1972 Jazz - 1.5" (38mm)
Fender Limited Gold Top Dusty Hill Precision - 1.5" (38mm)
Fender Mark Hoppus Jazz - 1.62" (41.3mm)
Fender Mike Dirnt Road Worn Precision - 1.59" (40.4mm)
Fender Modern Player Dimension - 1.5" (38mm)
Fender Modern Player Jaguar - 1.5" (38mm)
Fender Modern Player Jazz - 1.5" (38mm)
Fender Modern Player Jazz Satin - 1.5" (38mm)
Fender Modern Player Tele Bass - 1.62" (41.3mm)
Fender Musicmaster Bass (1st version) - 1.625" (41.3mm)
Fender Musicmaster Bass 1976 - 1.59" (40.4mm)
Fender Mustang Bass RI MIJ 2006 - 1.5" (38mm)
Fender Precision Bass Special Deluxe Series - 1.5" (38mm)
Fender Precision Elite - 1.75" (44.5mm)
Fender Precision LYTE Deluxe - 1.50" (38mm)
Fender Reggie Hamilton Jazz - 1.5" (38mm)
Fender Road Worn 50 P-Bass - 1.75" (44.5mm)
Fender Roger Waters Precision - 1.75" (44.5mm)
Fender Sean Hurley Signature 1961 Precision - 1.75" (44.45mm)
Fender Select Jazz - 1.5" (38mm)
Fender Select Precision - 1.62" (41.3mm)
Fender Standard Jazz - 1.5" (38mm)
Fender Starcaster (New) - 1.625" (41.3mm)
Fender Steve Harris P-Bass - 1.75" (44.5mm)
Fender Telecaster Bass - 1.75" (44.5mm)
Fender Troy Sanders Jaguar - 1.5" (38mm)
Fender Vintage Hot Rod '60s Precision - 1.625" (41.3mm)
Fender Vintage Hot Rod '70s Jazz - 1.5" (38mm)
G&L 2012 Special M-2000 - 1.75" (44.5mm)
G&L Asat Semi Hollow - 1.5" (38mm)
G&L L1K '81 - 1.703" (43.3mm)
G&L L1000 2014 - 1.709" (43.4mm)
G&L L-2000 - 1.79" (45.5mm)
G&L SB-2T '14 (#7 neck) - 1.718" (43.6mm)
G&L Tribute L-2000 - 1.75" (44.5mm)
G&L Tribute L2000 (2012/13) - 1.692" (43mm)
G&L Tribute JB-2 - 1.5" (38mm)
G&L Tribute SB-2 - 1.5" (38mm)
Gibson EB-2 (vintage) - 1.60" (42mm)
Gibson EB-3 (1965) - 1.69" (43mm)
Gibson EB-3 (1973) - 1.562" (39.7mm)
Gibson Les Paul Oversized - 1.6" (40.6mm)
Gibson SG-Bass - 1.60" (42mm)
Godin Shifter Bass - 1.5" (38,1mm)
Gretsch G2202 Junior Jet - 1.625" (41.3mm)
Gretsch G5440LSB Electromatic - 1.69" (43mm)
Gretsch White Falcon - 1.28" (32.5mm)
Guild Starfire Reissue - 1.5" (38mm)
Harley Benton HBZ-2004 - 1.57" (40mm)
Harley Benton JB-20 Standard - 1.5" (38mm)
Harley Benton PB-20 - 1.65" (42mm)
Harley Benton PB-50 - 1.65" (42mm)
Harley Benton PJ-4 Deluxe - 1.65" (42mm)
Harmony (unknown model 1991) - 1.65" (42mm)
Herby Custom Bass (MIJ. Ric copy 60's/70's) - 1.662" (42.2mm)
Hohner HAB-50 PS ABG - 1.668" (42.4mm)
Höfner 182 - 1.808" (45.9mm)
Hofner 500/1 - 1.65" (42mm)
Hofner Shorty - 1.69" (43mm)
Hondo Longhorn 1181 - 1.5" (38mm)
Ibanez AEB10 - 1.687" (42.84mm)
Ibanez AGB140 - 1.533" (39.4mm)
Ibanez Artcore AGB-200 Shortscale (2011) – 1.65” (42mm)
Ibanez EXB404 - 1.56" (39.6mm)
Ibanez GATK20 (2010-2011) - 1.673" (42.5mm)
Ibanez GSR200fm - 1.5625" (39.7mm)
Ibanez GSRM20 Mikro Bass - 1.5" (38mm)
Ibanez Musician MC-924 (1980) – 1.65” (42mm)
Ibanez Musician MC-940 (1982) – 1.614” (41mm)
Ibanez Roadstar II RB-920 (1983) – 1.575” (40mm)
Ibanez Roadster RS-824 (1981) – 1.594” (40.5mm)
Ibanez Roadster RS-940 (1980) – 1.65” (42mm)
Ibanez SR300 (2010) - 1.5” (38mm)
Ibanez SR4 - 1.5" (38mm)
Ibanez SR500 (2009) - 1.437" (36.5mm)
Ibanez SR500 (2012 approx.) - 1.5" (38mm)
Ibanez SRA500/SRA550 - 1.5" (38mm)
Ibanez SR600 - 1.5" (38mm)
Jack & Danny Jazz Bass - 1.5" (38mm)
Jackson C20 - 1.625" (41.3mm)
Jolana Diamant (Zech. LP) - 1.789" (45.7mm)
Lakland 44-64 Custom - 1.5" (38mm)
Lakland Skyline 44-01 - 1.65" (42mm)
Lakland USA Duck Dunn - 1.5" (38mm)
Mighty mite Jazz replacement neck (maple fingerboard) - 1,5" (38mm)
Mighty mite Precision replacement neck (maple fingerboard) - 1.62" (41,3mm)
Mike Lull P4 w/Jazz neck - 1.5" (38mm)
MTD Kingston Heir - 1.56" (39.6mm)
OLP MM2 (3rd generation, I believe) - 1.69" (43mm)
Peavey Forum P/J (1994) - 1.5" (38.1mm)
Peavey Foundation (1986) - 1.5" (38.1mm)
Peavey Foundation (1991 & 1992) = 1.5" (38mm)
Peavey Fury (1983 - slanted SF) - 1.75" (44.5mm)
Peavey Fury (1987) = 1.5" (38mm)
Peavey Fury (1990 - P) - 1.5" (38.1mm)
Peavey Fury (1991 & 1992) = 1.5" (38mm)
Peavey Milestone III Jazz Bass - 1.5" (38mm)
Peavey Milestone IV P Bass - 1.46" (37mm)
Peavey Millenium BXP Jazz - 1.5" (38mm)
Peavey Patriot (1985) - 1.6875" (42.86mm)
Peavey Patriot (1987) = 1.5" (38mm)
Peavey RJ-IV (1991) - 1.6" (40.6mm)
Peavey Sarzo (US - 1991) - 1.625" (41.3mm)
Peavey T-20 (1982) - 1.6875" (42.86mm)
Peavey T-40 (1979) - 1.6875" (42.86mm)
Peavey Unity (1991 Koa P/J) - 1.6" (40.6mm)
PRS #11 - 1.692" (43mm)
Rickenbacker 4001 (1979) - 1.71" (43.5mm)
Rickenbacker 4001 (1979) - 1.69" (43mm)
Rickenbacker 4001 (March 1973) - 1.625" (41.3mm)
Rickenbacker 4001V63 (April 1998) - 1.718" (43.6mm)
Rickenbacker 4003FL (1985) - 1.625" (41.275mm)
Rickenbacker 4004 Laredo (NAMM Show instrument-December 2011) - 1.687" (42.8mm)
Rick Turner Renaissance RB4FL (2005-NAMM Show instrument) - 1.5" (38mm)
Ritter R8 (Vintage 4) - 1.535" (39mm)
Rob Allen Mouse - 1.653" (42mm)
Roscoe Custom "Birdie" - 1.653" (42mm)
Roscoe Custom "Bucky" - 1.811" (46mm)
Sadowsky Metro RV4-WL - 1.45" (37mm)
Sadowsky NYC J4 - 1.5" (38mm)
Sadowsky NYC Will Lee - 1.45" (37mm)
Schecter Raiden Special 4 - 1.653” (42mm)
Schecter Stiletto Extreme 4 = 1.5" (38mm)
Sire M3 = 1.5" (38mm)
Spector Forte-4 - 1.61" (41mm)
Spector Legend 4 (1st Gen.) - 1.565" (39.75mm)
Spector Legend CLS - 1.5625" (39.7mm)
Spector Legend NS-2 - 1.5" (38mm)
Spector NS-2JA-R - 1.65" (42mm)
Squier Affinity Jazz - 1.5" (38mm)
Squier Affinity P-Bass - 1.62" (41.3mm)
Squier Bronco - 1.62" (41.3mm)
Squier Bronco (20th Anniversary Model) - 1.614" (41mm)
Squier Classic Vibe Jazz - 1.5" (38mm)
Squier Classic Vibe P-Bass 50 - 1.65" (42mm)
Squier Classic Vibe 60s P-Bass - 1.62" (41.3mm)
Squier Dimension - 1.57" (40mm)
Squier Jaguar Short Scale - 1.5" (38mm)
Squier Matt Freeman P-Bass - 1.65" (42mm)
Squier Mike Dirnt Precision - 1.65" (42mm)
Squier Mikey Way Mustang - 1.5" (38mm)
Squier Pro Tone Precision Bass - 1.5" (38mm)
Squier Troy Sanders Jaguar - 1.5" (38mm)
Squier Vintage Modified Cabronita Precision Bass - 1.625" (41.3mm)
Squier Vintage Modified Fretless Jazz - 1.5" (38mm)
Squier Vintage Modified Jaguar "Standard" - 1.5" (38mm)
Squier Vintage Modified Jazz - 1.5" (38mm)
Squier Vintage Modified Jazz '70S - 1.5" (38mm)
Squier Vintage Modified Jazz '77 - 1.5" (38mm)
Squier Vintage Modified Precision - 1.62" (41.1mm)
Squier Vintage Modified Precision Fretless - 1.625" (41.3mm)
Squier Vintage Modified Precision PJ - 1.625" (41.3mm)
Squier Vintage Modified Precision TB - 1.59" (40.5mm)
Squier Vintage Modified Telecaster - 1.732" (44mm)
Squier Vintage Modified Telecaster Bass IV - 1.7" (43.2 mm)
Steinberger XP2 '86 - 1.5" (38mm)
Sterling by Music Man Ray4 - 1.5" (38mm)
Sterling by Music Man SUB SB4 - 1.5" (38mm)
Stu Hamm Urge I (1985) - 1.614" (41mm)
Suhr Classic J - 1.5" (38mm)
SX SBG2 - 1.69" (43mm)
SX SWB1 - 1.5" (38mm)
SX Ursa 1 - 1.625" (42mm)
SX Ursa 1 - 1.687" (43mm)
Takamine B10 - 1.8125" (46mm)
Takamine EG512 - 1.6875" (43mm)
Traben Standard 4 - 1.5" (38mm)
Vantage VA-900B (1981) – 1.59” (40.5mm)
Vantage VA-900B/FL (1981) – 1.59” (40.5mm)
Viola Bass with Variax transplant - 1.712" 43.5mm
Wal Mk 1 Custom Series (Soft V Profile) - 1.625" (42mm)
Wal Pro Series (C Profile) - 1.6875" (43mm)
Warwick Alien - 1.535" (39mm)
Warwick Buzzard - 1.73" (44mm)
Warwick Corvette 4 = 1.5" (38mm)
Warwick Corvette 4 $$ = 1.5" (38mm)
Warwick Dolphin - 1.73" (44mm)
Warwick Rockbass COrvett Short Scale - 1.5" (38mm)
Warwick Streamer 4 = 1.5" (38mm)
Warwick Stryker - 1.73" (44mm)
Warwick "Other 4 Models" - 1.515" (38.5mm)
Warwick Thumb NT4 (2013) - 1.51" (38.4mm)
Washburn SHB40 = 1.65" (42mm)
Washburn T24 = 1.589" (40.4mm)
Yamaha Attitude Standard (1991) = 1.65” (42mm)
Yamaha BB404 - 1.5838" (40.48mm)
Yamaha BB Series (424 to 2024) - 1.57" (40mm)
Yamaha RBX170 = 1.57" (40mm)
Yamaha RBX300 (1990) - 1.57" (40mm)
Yamaha TRBX 504 - 1.5" (38mm)
Zon VB-4 (Vinny) - 1.532" (38.9mm)

5 STRINGS
Alembic Classic - 2.00" (50.8mm)
Alembic Comfort - 1.875" (47.6mm)
Carvin LB75 (1991) - 1.71" (43.5mm)
Conklin Groove Tools GT-5 - 1.751" (44.5mm)
Cort Action V - 1.77" (45mm)
Dean Sledgehammer 5 Ash – 1.75” (44.45mm)
EBMM Stingray 5 - 1.75" (44.45mm)
Epiphone Thunderbird (all 5 strings) 1.73" - (43.94mm)
ESP B55 - 1.692" (43mm)
ESP LTD B-1005 - 1.85" (47mm)
ESP LTD B-105 - 1.77" (45mm)
ESP LTD B-155DX - 1.77" (45mm)
ESP LTD B-335 - 1.77" (45mm)
ESP LTD B-5 JR Junior Black - 1.625" (41.3mm)
ESP LTD B205SM - 1.77" (45mm)
ESP D5 - 1.771" (45mm)
ESP LTD F-105 - 1.77" (45mm)
ESP LTD F-5E - 1.85" (47mm)
ESP Surveyor 5 - 1.5" (38mm)
Fender American Deluxe Jazz V - 1.875" (47.6mm)
Fender Am Std Dimension - 1.75" (44.45mm)
Fender Modern Player Jazz V Satin - 1.875" (47.6mm)
Fender Standard Jazz V - 1.85" (47mm)
G&L L-2500 - 1.75" (44.5mm)
G&L Tribute L-2500 - 1.75" (44.5mm)
Harley Benton B-500 Modern Series - 1.77" (45mm)
Harley Benton HBZ-2005 - 1.77" (45mm)
Harley Benton PJ-5 Deluxe - 1.77 "(45mm)
Ibanez ATK305 ? 1.75? (44.5mm)
Ibanez BTB 675 - 1.85" (47mm)
Ibanez EX (1994) - 1.76" (44.7mm)
Ibanez Gary Willis Signature GWB1 - 1.75" (44.5mm)
Ibanez Gary Willis Signature GWB2 - 1.75" (44.5mm)
Ibanez GSRM25 Mikro Bass 5 - 1.77" (45mm)
Ibanez Sr705 2014 - 1.693" (43mm)
Ibanez SR1205-VNF - 1.77" (45mm)
Ibanez SR5 - 1.77" (45mm)
Lakland 55-94 - 1.80" (45.7mm)
Lightwave Saber SL 5 (fretted) ? 1.75? (44.5mm)
Martin Keith Elfin 5 fretless (2010-NAMM Show instrument) - 1.875" (47.6mm)
Martin Keith Elfin 5 (2011) - 1.875" (47.6mm)
Modulus Bassstar - 1.75" (44.5mm)
Modulus Q5 - 1.85" (47mm)
Modulus Q5W19 - 1.90" (48.26mm)
Modulus Q5W21 - 2.00" (50.8mm)
MPG Level-5 Fretless - 1.81" (45.97mm)
Ritter Coda (Vintage 5) - 1.948" (49.5mm)
Ritter R8 (Vintage 5) - 1.948" (49.5mm)
Spector Coda-5DLX/XL - 1.87" (47.6mm)
Spector Coda Pro 5 - 1.75" (44.45mm)
Spector Core 5 - 1.75" (44.45mm)
Spector Euro5LX - 1.85" (46.99mm)
Spector Forte-5 - 1.81" (45.97mm)
Spector Legend Classic-5 - 1.75" (44.45mm)
Spector NS-5 - 1.80" (45.72mm)
Spector NS-5H2 (Wide-5 model) - 1.80" (45.72mm) or 1.88" (47.75mm)
Spector NS-5XL - 1.81" (45.97mm)
Spector Performer 5 - 1.75" (44.45mm)
Spector ReBop-5 - 1.81" (45.97mm)
Squier Affinity Jazz V - 1.87" (47.6mm)
Squier Deluxe Jazz V - 2" (51mm)
Squier Dimension - 1.75" (44.45mm)
Squier Standard P Bass Special 5 - 2.008" (51mm)
Squier Vintage Modified Jazz V - 1.87" (47.6mm)
Sterling by Music Man SUB - 1.77" (45mm)
Sterling by Music Man Ray5 - 1.77" (45mm)
Vintage Modified Precision V - 1.875" (47.6mm)
Steinberger Spirit 5 circa 2010, 1.75" (44.5mm)
Steinberger Synapse - 1.77" (44.96mm) @ 0 fret
Traben Array 5 - 1.78" (45.2mm)
Traben Array Limited - 1.78" (45.2mm)
Traben Chaos Core 5 - 1.78" (45.2mm)
Traben Standard 5 - 1.5" (38mm)
Wal 5-String Mark IIs - 1.85" (47mm)
Wal 5-String Mark IIIs - 1.85" (47mm)
Warwick "All 5 Models" - 1.771" (45mm) or 1.85" (47mm)
Yamaha BB1025 – 1.692” (43mm)
Yamaha BB415 - 1.653" (42mm)
Yamaha BBNE1/BBEAST - 1.875" (47.62mm)
Yamaha TRBX 505 - 1.692" (43mm)
Zon 5/1 (circa 1996) - 1.85" (47mm)

6 STRINGS
Brice Z6 – 2.126” (54mm)
Carvin LB76 - 2.02" (51.3mm)
Harley Benton HBB600TBK - 2.175" (55.2mm)
Harley Benton HBB6000 - 2.095" (53.2mm)
Ibanez BTB 456 – 2.126” (54mm)
Roscoe 3006 - 2.150" (54.61mm)
Squier Vintage Modified Bass VI - 1.65" (42mm)
Tune TWB63WN - 2.291" (58.2mm)
Warwick "All 6 Models" - 2.047" (52mm) or 2.165" (55mm)
Yamaha RBX6JM (2000 mk i) -1.968" 50mm
Yamaha TRB 6II – 2.047” (52mm)
Yamaha TRB JP2 – 2.205” (56mm)

7 STRINGS
Roscoe SKB 3007 - 2.470" (63.14mm)
Wolf WTHB-7W - 2.418" (61.4mm)
Zdressy Fretless (2016) - 2.36" (59.9mm)

8 STRINGS
Ibanez Musician MC-980 (1980) – 1.692” (43mm)

  • Like
Reactions: Chico Ruger and pbass74
#230
Maruszczyk Elwood Absolution 4 - 40mm

Adding a picture, 'cause it's bloody beautiful!

  • Like
Reactions: JACink
#232
Here are my contributions (I see information listed here that conflicts with my measurements for the Squier VM).

4 string
Fender Limited Edition American PJ (2016 Magnificent 7) 1.52" (38mm)
Squier Vintage Modified PJ (2014 Indonesia) 1.61" (41mm)
Squier Classic Vibe 70s P (2015 China) 1.61" (41mm)
Johnson JG-622-E Acoustic (China) 1.73" (44mm)

5 string
Schecter Diamond Series Elite-5 1.79" (45.5mm)

Thumpin...

Last edited:
  • Like
Reactions: JACink
#233
List updated, thank you @Inara , @mongo2 , @aah_scary , @acroce , @RandyC :thumbsup:

CURRENT LIST:

4 STRINGS
Alembic Classic: 1.75" (44.5mm)
Alembic Comfort: 1.625" (41.3mm)
Alembic Slender: 1.5" (38mm)
Alleva RA 4 string: 1.5" (38mm)
Andrew Drake "Wilma" - 1.653" (42mm)
Aria A-200 - 1.44" (36.6mm)
Aria Rock 'n' Roller 4001 - 1.59" (40.5mm)
Aria SB700 - 1.811" (46mm)
Aslin Dane Jazz Copy - 1.62" (41.3mm)
BC Rich Warlock Platinum Series - 1.65" (42mm)
Carvin LB70 - 1.54" (39.1mm)
Cort C4H (<2009) - 1.57" (40mm)
Cort C4H (>2010) - 1.5" (38mm)
Danelectro 63 RI (MIK) - 1.625" (41.3mm)
Dean USA Hillsboro - 1.5" (38mm)
Eastwood Classic 4 - 1.5" (38mm)
Eastwood HiFlyer - 1.86" (47mm)
EBMM Bongo 4 - 1.625" (41.3 mm)
EBMM Caprice - 1.5" (38mm)
EBMM Cutlass: 1.625" (41.3 mm)
EBMM Ray 34 - 1.69" (43mm)
EBMM Sig.4 - 1.5" (38mm)
EBMM Sterling - 1.5" (38mm)
EBMM Stingray - 1.625" (41.3mm)
EBMM StingRay (1995) - 1.69" (42.9mm)
EBMM Stingray SLO - 1.5" (38mm)
EPI LTD Explorer = 1.662" (42.2mm)
Epiphone EB-0 - 1.5" (38mm)
Epiphone Jack Casady Signature - 1.65" (42mm)
Epiphone Thunderbird IV - 1.73" (43.9mm)
Epiphone Thunderbird pro-IV - 1.5" (38mm)
Epiphone Thunderbird (all 4 strings) - 1.5" (38mm)
Epiphone Toby Deluxe IV - 1.68" (42.67mm)
Epiphone Toby STandard IV - 1.68" (42.67mm)
ESP B-4 - 1.57" (40mm)
ESP D-4 - 1.57" (40mm)
ESP LTD B-154DX - 1.57" (40mm)
ESP LTD B204SM - 1.57" (40mm)
ESP LTD B-4E - 1.65" (42mm)
ESP LTD EC-104 - 1.57" (40mm)
ESP LTD F-414FM - 1.65" (42mm)
ESP LTD FB-4 Frank Bello - 1.65" (42mm)
ESP LTD GC-4 - 1.57" (40mm)
ESP LTD PT-4 Pancho Tomaseli - 1.77" (45mm)
ESP LTD Vintage-204 - 1.65" (42mm)
Faith Titan Neptune ABG - 1.673" (42.5mm)
Fender 56 Precision - 1.73" (43.9mm)
Fender 59 Precision - 1.71" (43.5mm)
Fender 60 Classic Jazz - 1.5" (38mm)
Fender 62RI Jazz - 1.5" (38mm)
Fender 64 Jazz - 1.5" (38mm)
Fender 67 Precision - 1.625" (41mm)
Fender 68 Telecaster - 1.75" (44.5mm)
Fender 69 Telecaster - 1.81" (45.9mm)
Fender 70 Classic Jazz - 1.5" (38mm)
Fender 70s Precision - 1.62" (41.3mm)
Fender 73 Precision (B Neck) - 1.64" (41.7mm)
Fender 82 Fullerton 57 Precision RI - 1.78" (45.2mm)
Fender '82 MIA Bullet B30 - 1.625" (41.3mm)
Fender Aerodyne Jazz - 1.5" (38mm)
Fender American Deluxe Jazz - 1.5" (38mm)
Fender American Deluxe P-Bass - 1.62" (41.3mm)
Fender American Hot Rod Precision '99 - 1.644" (41.8mm)
Fender American Special Jazz - 1.5" (38mm)
Fender American Special P-Bass - 1.69" (43mm)
Fender American Standard (1st version) '88-'94 - 1.5" (38mm)
Fender Antigua Precision - 1.62" (41.3mm)
Fender AVRI '57 & '62 P-bass - 1.75" (44.5mm)
Fender BG29 Bass - 1,70" (43.2mm)
Fender Blacktop Jazz - 1.5" (38mm)
Fender Blacktop Precision - 1.62" (41.3mm)
Fender Cabronita Precision (MIM) = 1.65” (42mm)
Fender Coronado (New) - 1.625" (41.3 mm)
Fender Coronado (vintage) - 1.5" (38mm)
Fender Custom Shop '59 NOS P - 1.75" (44.5mm)
Fender Custom Shop '64 Jazz Bass (NOS) - 1.5" (38mm)
Fender Custom Shop Jazz - 1.5" (38mm)
Fender Dimension - 1.5625" (39.6mm)
Fender Duff McKagan P-Bass - 1.62" (41.3mm)
Fender FR 51 Resonator Bass - 1.69" (43mm)
Fender Geddy Lee Jazz Bass (CIJ) - 1.5" (38mm)
Fender Geddy Lee USA Jazz = 1.55" (39.4mm)
Fender HM - 1.5" (38mm)
Fender Jazz Bass (original) - 1.437" (36.5mm)
Fender Jazz Plus '90-'94 - 1.5" (38mm)
Fender Jazz Special (mid 80's MIJ) - 1.5" (38mm)
Fender Jazz Special (1987) - 1.528" (38.8mm)
Fender Japan PJM-65R "Jazz Special" (1985) - 1.515" (38.5mm)
Fender Kingman AB - 1.5" (38mm)
Fender Limited Edition American PJ (2016 Magnificent 7) - 1.52" (38mm)
Fender Limited Geddy Lee 1972 Jazz - 1.5" (38mm)
Fender Limited Gold Top Dusty Hill Precision - 1.5" (38mm)
Fender Mark Hoppus Jazz - 1.62" (41.3mm)
Fender Mike Dirnt Road Worn Precision - 1.59" (40.4mm)
Fender Modern Player Dimension - 1.5" (38mm)
Fender Modern Player Jaguar - 1.5" (38mm)
Fender Modern Player Jazz - 1.5" (38mm)
Fender Modern Player Jazz Satin - 1.5" (38mm)
Fender Modern Player Tele Bass - 1.62" (41.3mm)
Fender Musicmaster Bass (1st version) - 1.625" (41.3mm)
Fender Musicmaster Bass 1976 - 1.59" (40.4mm)
Fender Mustang Bass RI MIJ 2006 - 1.5" (38mm)
Fender Precision Bass Special Deluxe Series - 1.5" (38mm)
Fender Precision Elite - 1.75" (44.5mm)
Fender Precision LYTE Deluxe - 1.50" (38mm)
Fender Reggie Hamilton Jazz - 1.5" (38mm)
Fender Road Worn 50 P-Bass - 1.75" (44.5mm)
Fender Roger Waters Precision - 1.75" (44.5mm)
Fender Sean Hurley Signature 1961 Precision - 1.75" (44.45mm)
Fender Select Jazz - 1.5" (38mm)
Fender Select Precision - 1.62" (41.3mm)
Fender Standard Jazz - 1.5" (38mm)
Fender Starcaster (New) - 1.625" (41.3mm)
Fender Steve Harris P-Bass - 1.75" (44.5mm)
Fender Telecaster Bass - 1.75" (44.5mm)
Fender Troy Sanders Jaguar - 1.5" (38mm)
Fender Vintage Hot Rod '60s Precision - 1.625" (41.3mm)
Fender Vintage Hot Rod '70s Jazz - 1.5" (38mm)
G&L 2012 Special M-2000 - 1.75" (44.5mm)
G&L Asat Semi Hollow - 1.5" (38mm)
G&L L1K '81 - 1.703" (43.3mm)
G&L L1000 2014 - 1.709" (43.4mm)
G&L L-2000 - 1.79" (45.5mm)
G&L SB-2T '14 (#7 neck) - 1.718" (43.6mm)
G&L Tribute L-2000 - 1.75" (44.5mm)
G&L Tribute L2000 (2012/13) - 1.692" (43mm)
G&L Tribute JB-2 - 1.5" (38mm)
G&L Tribute SB-2 - 1.5" (38mm)
Gibson EB-2 (vintage) - 1.60" (42mm)
Gibson EB-3 (1965) - 1.69" (43mm)
Gibson EB-3 (1973) - 1.562" (39.7mm)
Gibson Les Paul Oversized - 1.6" (40.6mm)
Gibson SG-Bass - 1.60" (42mm)
Godin Shifter Bass - 1.5" (38,1mm)
Gretsch G2202 Junior Jet - 1.625" (41.3mm)
Gretsch G5440LSB Electromatic - 1.69" (43mm)
Gretsch White Falcon - 1.28" (32.5mm)
Guild Starfire Reissue - 1.5" (38mm)
Harley Benton HBZ-2004 - 1.57" (40mm)
Harley Benton JB-20 Standard - 1.5" (38mm)
Harley Benton PB-20 - 1.65" (42mm)
Harley Benton PB-50 - 1.65" (42mm)
Harley Benton PJ-4 Deluxe - 1.65" (42mm)
Harmony (unknown model 1991) - 1.65" (42mm)
Herby Custom Bass (MIJ. Ric copy 60's/70's) - 1.662" (42.2mm)
Hohner HAB-50 PS ABG - 1.668" (42.4mm)
Höfner 182 - 1.808" (45.9mm)
Hofner 500/1 - 1.65" (42mm)
Hofner Ignition Club - 1.531" (38.9mm)
Hofner Shorty - 1.69" (43mm)
Hondo Longhorn 1181 - 1.5" (38mm)
Ibanez AEB10 - 1.687" (42.84mm)
Ibanez AFB200 - 1.625" (41.3mm)
Ibanez AGB140 - 1.533" (39.4mm)
Ibanez Artcore AGB-200 Shortscale (2011) – 1.65” (42mm)
Ibanez EXB404 - 1.56" (39.6mm)
Ibanez GATK20 (2010-2011) - 1.673" (42.5mm)
Ibanez GSR200fm - 1.5625" (39.7mm)
Ibanez GSRM20 Mikro Bass - 1.5" (38mm)
Ibanez Musician MC-924 (1980) – 1.65” (42mm)
Ibanez Musician MC-940 (1982) – 1.614” (41mm)
Ibanez RB850 (1985) - 1.585" (40.33mm)
Ibanez Roadstar II RB-920 (1983) – 1.575” (40mm)
Ibanez Roadster RS-824 (1981) – 1.594” (40.5mm)
Ibanez Roadster RS-940 (1980) – 1.65” (42mm)
Ibanez SR300 (2010) - 1.5” (38mm)
Ibanez SR4 - 1.5" (38mm)
Ibanez SR500 (2009) - 1.437" (36.5mm)
Ibanez SR500 (2012 approx.) - 1.5" (38mm)
Ibanez SRA500/SRA550 - 1.5" (38mm)
Ibanez SR600 - 1.5" (38mm)
Jack & Danny Jazz Bass - 1.5" (38mm)
Jackson C20 - 1.625" (41.3mm)
Johnson JG-622-E Acoustic (China) - 1.73" (44mm)
Jolana Diamant (Zech. LP) - 1.789" (45.7mm)
Lakland 44-64 Custom - 1.5" (38mm)
Lakland Skyline 44-01 - 1.65" (42mm)
Lakland USA Duck Dunn - 1.5" (38mm)
Maruszczyk Elwood Absolution 4 - 1.574" (40mm)
Mighty mite Jazz replacement neck (maple fingerboard) - 1,5" (38mm)
Mighty mite Precision replacement neck (maple fingerboard) - 1.62" (41,3mm)
Mike Lull P4 w/Jazz neck - 1.5" (38mm)
MTD Kingston Heir - 1.56" (39.6mm)
OLP MM2 (3rd generation, I believe) - 1.69" (43mm)
Peavey Forum P/J (1994) - 1.5" (38.1mm)
Peavey Foundation (1986) - 1.5" (38.1mm)
Peavey Foundation (1991 & 1992) = 1.5" (38mm)
Peavey Fury (1983 - slanted SF) - 1.75" (44.5mm)
Peavey Fury (1987) = 1.5" (38mm)
Peavey Fury (1990 - P) - 1.5" (38.1mm)
Peavey Fury (1991 & 1992) = 1.5" (38mm)
Peavey Milestone III Jazz Bass - 1.5" (38mm)
Peavey Milestone IV P Bass - 1.46" (37mm)
Peavey Millenium BXP Jazz - 1.5" (38mm)
Peavey Patriot (1985) - 1.6875" (42.86mm)
Peavey Patriot (1987) = 1.5" (38mm)
Peavey RJ-IV (1991) - 1.6" (40.6mm)
Peavey Sarzo (US - 1991) - 1.625" (41.3mm)
Peavey T-20 (1982) - 1.6875" (42.86mm)
Peavey T-40 (1979) - 1.6875" (42.86mm)
Peavey Unity (1991 Koa P/J) - 1.6" (40.6mm)
PRS #11 - 1.692" (43mm)
Rickenbacker 4001 (1979) - 1.71" (43.5mm)
Rickenbacker 4001 (1979) - 1.69" (43mm)
Rickenbacker 4001 (March 1973) - 1.625" (41.3mm)
Rickenbacker 4001V63 (April 1998) - 1.718" (43.6mm)
Rickenbacker 4003FL (1985) - 1.625" (41.275mm)
Rickenbacker 4004 Laredo (NAMM Show instrument-December 2011) - 1.687" (42.8mm)
Rick Turner Renaissance RB4FL (2005-NAMM Show instrument) - 1.5" (38mm)
Ritter R8 (Vintage 4) - 1.535" (39mm)
Rob Allen Mouse - 1.653" (42mm)
Roscoe Custom "Birdie" - 1.653" (42mm)
Roscoe Custom "Bucky" - 1.811" (46mm)
Sadowsky Metro RV4-WL - 1.45" (37mm)
Sadowsky NYC J4 - 1.5" (38mm)
Sadowsky NYC Will Lee - 1.45" (37mm)
Steinberger Synapse XS1-FPA 4-string - 1.534" (38.98mm) (at zero fret)
Schecter Raiden Special 4 - 1.653” (42mm)
Schecter Stiletto Extreme 4 = 1.5" (38mm)
Sire M3 = 1.5" (38mm)
Spector Forte-4 - 1.61" (41mm)
Spector Legend 4 (1st Gen.) - 1.565" (39.75mm)
Spector Legend CLS - 1.5625" (39.7mm)
Spector Legend NS-2 - 1.5" (38mm)
Spector NS-2JA-R - 1.65" (42mm)
Squier Affinity Jazz - 1.5" (38mm)
Squier Affinity P-Bass - 1.62" (41.3mm)
Squier Bronco - 1.62" (41.3mm)
Squier Bronco (20th Anniversary Model) - 1.614" (41mm)
Squier Classic Vibe Jazz - 1.5" (38mm)
Squier Classic Vibe P-Bass 50 - 1.65" (42mm)
Squier Classic Vibe 60s P-Bass - 1.62" (41.3mm)
Squier Classic Vibe 70s P (2015 China) 1.61" (41mm)
Squier Dimension - 1.57" (40mm)
Squier Jaguar Short Scale - 1.5" (38mm)
Squier Matt Freeman P-Bass - 1.65" (42mm)
Squier Mike Dirnt Precision - 1.65" (42mm)
Squier Mikey Way Mustang - 1.5" (38mm)
Squier Pro Tone Precision Bass - 1.5" (38mm)
Squier Troy Sanders Jaguar - 1.5" (38mm)
Squier Vintage Modified Cabronita Precision Bass - 1.625" (41.3mm)
Squier Vintage Modified Fretless Jazz - 1.5" (38mm)
Squier Vintage Modified Jaguar "Standard" - 1.5" (38mm)
Squier Vintage Modified Jazz - 1.5" (38mm)
Squier Vintage Modified Jazz '70S - 1.5" (38mm)
Squier Vintage Modified Jazz '77 - 1.5" (38mm)
Squier Vintage Modified Precision - 1.62" (41.1mm)
Squier Vintage Modified Precision Fretless - 1.625" (41.3mm)
Squier Vintage Modified Precision PJ - 1.625" (41.3mm)
Squier Vintage Modified PJ (2014 Indonesia) 1.61" (41mm) (measured by TBer)
Squier Vintage Modified Precision TB - 1.59" (40.5mm)
Squier Vintage Modified Telecaster - 1.732" (44mm)
Squier Vintage Modified Telecaster Bass IV - 1.7" (43.2 mm)
Steinberger XP2 '86 - 1.5" (38mm)
Sterling by Music Man Ray4 - 1.5" (38mm)
Sterling by Music Man SUB SB4 - 1.5" (38mm)
Stu Hamm Urge I (1985) - 1.614" (41mm)
Suhr Classic J - 1.5" (38mm)
SX SBG2 - 1.69" (43mm)
SX SWB1 - 1.5" (38mm)
SX Ursa 1 - 1.625" (42mm)
SX Ursa 1 - 1.687" (43mm)
Takamine B10 - 1.8125" (46mm)
Takamine EG512 - 1.6875" (43mm)
Traben Standard 4 - 1.5" (38mm)
Vantage VA-900B (1981) – 1.59” (40.5mm)
Vantage VA-900B/FL (1981) – 1.59” (40.5mm)
Viola Bass with Variax transplant - 1.712" 43.5mm
Wal Mk 1 Custom Series (Soft V Profile) - 1.625" (42mm)
Wal Pro Series (C Profile) - 1.6875" (43mm)
Warwick Alien - 1.535" (39mm)
Warwick Buzzard - 1.73" (44mm)
Warwick Corvette 4 = 1.5" (38mm)
Warwick Corvette 4 $$ = 1.5" (38mm)
Warwick Dolphin - 1.73" (44mm)
Warwick Rockbass COrvett Short Scale - 1.5" (38mm)
Warwick Streamer 4 = 1.5" (38mm)
Warwick Stryker - 1.73" (44mm)
Warwick "Other 4 Models" - 1.515" (38.5mm)
Warwick Thumb NT4 (2013) - 1.51" (38.4mm)
Washburn SHB40 = 1.65" (42mm)
Washburn T24 = 1.589" (40.4mm)
Yamaha Attitude Standard (1991) = 1.65” (42mm)
Yamaha BB404 - 1.5838" (40.48mm)
Yamaha BB Series (424 to 2024) - 1.57" (40mm)
Yamaha RBX170 = 1.57" (40mm)
Yamaha RBX300 (1990) - 1.57" (40mm)
Yamaha TRBX 504 - 1.5" (38mm)
Zon VB-4 (Vinny) - 1.532" (38.9mm)

5 STRINGS
Alembic Classic - 2.00" (50.8mm)
Alembic Comfort - 1.875" (47.6mm)
Carvin LB75 (1991) - 1.71" (43.5mm)
Conklin Groove Tools GT-5 - 1.751" (44.5mm)
Cort Action V - 1.77" (45mm)
Dean Sledgehammer 5 Ash – 1.75” (44.45mm)
EBMM Stingray 5 - 1.75" (44.45mm)
Epiphone Thunderbird (all 5 strings) 1.73" - (43.94mm)
ESP B55 - 1.692" (43mm)
ESP LTD B-1005 - 1.85" (47mm)
ESP LTD B-105 - 1.77" (45mm)
ESP LTD B-155DX - 1.77" (45mm)
ESP LTD B-335 - 1.77" (45mm)
ESP LTD B-5 JR Junior Black - 1.625" (41.3mm)
ESP LTD B205SM - 1.77" (45mm)
ESP D5 - 1.771" (45mm)
ESP LTD F-105 - 1.77" (45mm)
ESP LTD F-5E - 1.85" (47mm)
ESP Surveyor 5 - 1.5" (38mm)
Fender American Deluxe Jazz V - 1.875" (47.6mm)
Fender Am Std Dimension - 1.75" (44.45mm)
Fender Modern Player Jazz V Satin - 1.875" (47.6mm)
Fender Standard Jazz V - 1.85" (47mm)
G&L L-2500 - 1.75" (44.5mm)
G&L Tribute L-2500 - 1.75" (44.5mm)
Harley Benton B-500 Modern Series - 1.77" (45mm)
Harley Benton HBZ-2005 - 1.77" (45mm)
Harley Benton PJ-5 Deluxe - 1.77 "(45mm)
Ibanez ATK305 ? 1.75? (44.5mm)
Ibanez BTB 675 - 1.85" (47mm)
Ibanez EX (1994) - 1.76" (44.7mm)
Ibanez Gary Willis Signature GWB1 - 1.75" (44.5mm)
Ibanez Gary Willis Signature GWB2 - 1.75" (44.5mm)
Ibanez GSRM25 Mikro Bass 5 - 1.77" (45mm)
Ibanez Sr705 2014 - 1.693" (43mm)
Ibanez SR1205-VNF - 1.77" (45mm)
Ibanez SR5 - 1.77" (45mm)
Lakland 55-94 - 1.80" (45.7mm)
Lightwave Saber SL 5 (fretted) ? 1.75? (44.5mm)
Martin Keith Elfin 5 fretless (2010-NAMM Show instrument) - 1.875" (47.6mm)
Martin Keith Elfin 5 (2011) - 1.875" (47.6mm)
Modulus Bassstar - 1.75" (44.5mm)
Modulus Q5 - 1.85" (47mm)
Modulus Q5W19 - 1.90" (48.26mm)
Modulus Q5W21 - 2.00" (50.8mm)
MPG Level-5 Fretless - 1.81" (45.97mm)
Ritter Coda (Vintage 5) - 1.948" (49.5mm)
Ritter R8 (Vintage 5) - 1.948" (49.5mm)
Schecter Diamond Series Elite-5 - 1.79" (45.5mm)
Spector Coda-5DLX/XL - 1.87" (47.6mm)
Spector Coda Pro 5 - 1.75" (44.45mm)
Spector Core 5 - 1.75" (44.45mm)
Spector Euro5LX - 1.85" (46.99mm)
Spector Forte-5 - 1.81" (45.97mm)
Spector Legend Classic-5 - 1.75" (44.45mm)
Spector NS-5 - 1.80" (45.72mm)
Spector NS-5H2 (Wide-5 model) - 1.80" (45.72mm) or 1.88" (47.75mm)
Spector NS-5XL - 1.81" (45.97mm)
Spector Performer 5 - 1.75" (44.45mm)
Spector ReBop-5 - 1.81" (45.97mm)
Squier Affinity Jazz V - 1.87" (47.6mm)
Squier Deluxe Jazz V - 2" (51mm)
Squier Dimension - 1.75" (44.45mm)
Squier Standard P Bass Special 5 - 2.008" (51mm)
Squier Vintage Modified Jazz V - 1.87" (47.6mm)
Sterling by Music Man SUB - 1.77" (45mm)
Sterling by Music Man Ray5 - 1.77" (45mm)
Vintage Modified Precision V - 1.875" (47.6mm)
Steinberger Spirit 5 circa 2010, 1.75" (44.5mm)
Steinberger Synapse - 1.77" (44.96mm) @ 0 fret
Traben Array 5 - 1.78" (45.2mm)
Traben Array Limited - 1.78" (45.2mm)
Traben Chaos Core 5 - 1.78" (45.2mm)
Traben Standard 5 - 1.5" (38mm)
Wal 5-String Mark IIs - 1.85" (47mm)
Wal 5-String Mark IIIs - 1.85" (47mm)
Warwick "All 5 Models" - 1.771" (45mm) or 1.85" (47mm)
Yamaha BB1025 – 1.692” (43mm)
Yamaha BB415 - 1.653" (42mm)
Yamaha BBNE1/BBEAST - 1.875" (47.62mm)
Yamaha TRBX 505 - 1.692" (43mm)
Zon 5/1 (circa 1996) - 1.85" (47mm)

6 STRINGS
Brice Z6 – 2.126” (54mm)
Carvin LB76 - 2.02" (51.3mm)
Harley Benton HBB600TBK - 2.175" (55.2mm)
Harley Benton HBB6000 - 2.095" (53.2mm)
Ibanez BTB 456 – 2.126” (54mm)
Roscoe 3006 - 2.150" (54.61mm)
Squier Vintage Modified Bass VI - 1.65" (42mm)
Tune TWB63WN - 2.291" (58.2mm)
Warwick "All 6 Models" - 2.047" (52mm) or 2.165" (55mm)
Yamaha RBX6JM (2000 mk i) -1.968" 50mm
Yamaha TRB 6II – 2.047” (52mm)
Yamaha TRB JP2 – 2.205” (56mm)

7 STRINGS
Roscoe SKB 3007 - 2.470" (63.14mm)
Wolf WTHB-7W - 2.418" (61.4mm)
Zdressy Fretless (2016) - 2.36" (59.9mm)

8 STRINGS
Ibanez Musician MC-980 (1980) – 1.692” (43mm)

#238
JACink said:
4 STRINGS
Alembic Classic: 1.75" (44.5mm)
Alembic Comfort: 1.625" (41,3mm)
Alembic Slender: 1.5" (38mm)
Eastwood Classic 4 - 1.5" (38mm)
Eastwood HiFlyer - 1.86" (47mm)
EPI LTD Explorer = 1.662" (42.2mm)
Epiphone Thunderberd IV: 1.75" (44.5mm)
Epiphone Thunderbird pro-IV: 1.5" (38mm)
Epiphone Toby Deluxe IV - 1.68" (42.67mm)
Epiphone Toby STandard IV - 1.68" (42.67mm)
ESP LTD B-154DX - 1.57" (40mm)
ESP LTD B204SM - 1.57" (40mm)
ESP LTD B-4E - 1.65" (42mm)
ESP LTD EC-104 - 1.57" (40mm)
ESP LTD F-414FM - 1.65" (42mm)
ESP LTD FB-4 Frank Bello - 1.65" (42mm)
ESP LTD GC-4 - 1.57" (40mm)
ESP LTD PT-4 Pancho Tomaseli - 1.77" (45mm)
ESP LTD Vintage-204 - 1.65" (42mm)
Fender 59 Precision - 1.71" (43.5mm)
Fender 60 Classic Jazz - 1.5" (38mm)
Fender 62RI Jazz - 1.5" (38mm)
Fender 64 Jazz - 1.5" (38mm)
Fender 70 Classic Jazz - 1.5" (38mm)
Fender 70s Precision - 1.62" (41.3mm)
Fender Aerodyne Jazz - 1.5" (38mm)
Fender American Deluxe Jazz - 1.5" (38mm)
Fender American Deluxe P-Bass - 1.62" (41.3mm)
Fender American Special Jazz - 1.5" (38mm)
Fender American Special P-Bass - 1.69" (43mm)
Fender Antigua Precision - 1.62" (41.3mm)
Fender AVRI '57 & '62 P-bass - 1.75" (44.5mm)
Fender Blacktop Jazz - 1.5" (38mm)
Fender Blacktop Precision - 1.62" (41.3mm)
Fender Coronado (vintage) - 1.5" (38mm)
Fender Duff McKagan P-Bass - 1.62" (41.3mm)
Fender Jazz Bass (original) - 1.437" (36.5mm)
Fender Jazz Special (mid 80's MIJ) - 1.5" (38mm)
Fender Kingman AB - 1.5" (38mm)
Fender Mark Hoppus Jazz - 1.62" (41.3mm)
Fender Modern Player Jaguar - 1.5" (38mm)
Fender Modern Player Jazz - 1.5" (38mm)
Fender Moder Player Tele Bass - 1.62" (41.3mm)
Fender Reggie Hamilton Jazz - 1.5" (38mm)
Fender Road Worn 50 P-Bass - 1.75" (44.5mm)
Fender Roger Waters Precision - 1.75" (44.5mm)
Fender Select Jazz - 1.5" (38mm)
Fender Select Precision - 1.62" (41.3mm)
Fender Standard Jazz - 1.5" (38mm)
Fender Steve Harris P-Bass - 1.75" (44.5mm)
G&L 2012 Special M-2000 - 1.75" (44.5mm)
G&L Asat Semi Hollow - 1.5" (38mm)
G&L L-2000 - 1.79" (45.5mm)
G&L Tribute L-2000 - 1.75" (44.5mm)
Gibson EB-2 (vintage) - 1.60" (42mm)
Gibson Les Paul Oversized - 1.6" (40.6mm)
Gibson SG-Bass - 1.60" (42mm)
Godin Shifter Bass - 1.5" (38,1mm)
Gretsch G5440LSB Electromatic - 1.69" (43mm)
Guild Starfire Reissue - 1.5" (38mm)
Harley Benton HBZ-2004 - 1.57" (40mm)
Harley Benton JB-20 Standard - 1.5" (38mm)
Harley Benton PB-20 - 1.65" (42mm)
Harley Benton PJ-4 Deluxe - 1.65" (42mm)
Herby Custom Bass (MIJ. Ric copy 60's/70's) - 1.662" (42.2mm)
Hohner HAB-50 PS ABG - 1.668" (42.4mm)
Höfner 182 - 1.808" (45.9mm)
Hofner Shorty - 1.69" (43mm)
Ibanez AEB10 = 1.687" (42.84mm)
Ibanez GSR200fm - 1.5625" (39.7mm)
Ibanez SR4 - 1.5" (38mm)
Ibanez SR500 (2009) = 1.437" (36.5mm)
Jack & Danny Jazz Bass - 1.5" (38mm)
Jackson C20 - 1.625" (41.3mm)
Jolana Diamant (Zech. LP) - 1.789" (45.7mm)
Lakland 44-64 Custom - 1.5" (38mm)
Rickenbacker 4001 (March 1973) - 1.625" (41.3mm)
Rickenbacker 4001V63 (April 1998) - 1.718" (43.6mm)
Rickenbacker 4004 Laredo (NAMM Show instrument-December 2011) - 1.687" (42.8mm)
Rick Turner Renaissance RB4FL (2005-NAMM Show instrument) - 1.5" (38mm)
Sadowsky NYC J4 - 1.5" (38mm)
Spector Legend CLS - 1.5625" (39.7mm)
Squier Affinity Jazz - 1.5" (38mm)
Squier Affinity P-Bass - 1.62" (41.3mm)
Squier Classic Vibe Jazz - 1.5" (38mm)
Squier Classic Vibe P-Bass 50 - 1.65" (42mm)
Squier Classic Vibe 60s P-Bass - 1.62" (41.3mm)
Squier Matt Freeman P-Bass - 1.65" (42mm)
Squier Mikey Way Mustang - 1.5" (38mm)
Squier Vintage Modified Fretless Jazz - 1.5" (38mm)
Squier Vintage Modified Jaguar "Standard" - 1.5" (38mm)
Squier Vintage Modified Jazz - 1.5" (38mm)
Squier Vintage Modified Precision - 1.62" (41.1mm)
Squier Vintage Modified Precision TB - 1.59" (40.5mm)
Traben Standard 4 - 1.5" (38mm)
Warwick ALL MODELS - en/Home.html
Washburn T24 = 1.589" (40.4mm)
Yamaha BB Series (424 to 2024) - 1.57" (40mm)

5 STRINGS
Alembic Classic - 2.00" (50.8mm)
Alembic Comfort - 1.875" (47.6mm)
ESP B55 - 1.692" (43mm)
ESP LTD B-105 - 1.77" (45mm)
ESP LTD B-155DX - 1.77" (45mm)
ESP LTD B-335 - 1.77" (45mm)
ESP LTD B205SM - 1.77" (45mm)
ESP D5 - 1.771" (45mm)
ESP LTD F-105 - 1.77" (45mm)
ESP LTD F-5E - 1.85" (47mm)
ESP Surveyor 5 - 1.5" (38mm)
Fender Standard Jazz V - 1.85" (47mm)
Fender American Deluxe Jazz V - 1.875" (47.6mm)
G&L L-2500 - 1.75" (44.5mm)
G&L Tribute L-2500 - 1.75" (44.5mm)
Harley Benton B-500 Modern Series - 1.77" (45mm)
Harley Benton HBZ-2005 - 1.77" (45mm)
Harley Benton PJ-5 Deluxe - 1.77 "(45mm)
Ibanez SR1205-VNF - 1.77" (45mm)
Ibanez SR5 - 1.77" (45mm)
Martin Keith Elfin 5 fretless (2010-NAMM Show instrument) - 1.875" (47.6mm)
Martin Keith Elfin 5 (2011) - 1.875" (47.6mm)
Squier Affinity Jazz V - 1.87" (47.6mm)
Squier Deluxe Jazz V - 2" (51mm)
Squier Vintage Modified Jazz V - 1.87" (47.6mm)
Traben Array 5 - 1.78" (45.2mm)
Traben Array Limited - 1.78" (45.2mm)
Traben Chaos Core 5 - 1.78" (45.2mm)
Traben Standard 5 - 1.5" (38mm)

6 STRINGS
Harley Benton HBB600TBK - 2.175" (55.2mm)
Harley Benton HBB6000 = 2.095" (53.2mm)
Click to expand...

On the Roger Waters P Bass what is the string spacing measurements at the bridge????

#240
Updated, thanks to @KeithAlanK , @bholder , @J_Bass , @Whil57 & @CorrosionMedia :thumbsup:

CURRENT LIST:

4 STRINGS
Alembic Classic: 1.75" (44.5mm)
Alembic Comfort: 1.625" (41.3mm)
Alembic Slender: 1.5" (38mm)
Alleva RA 4 string: 1.5" (38mm)
Andrew Drake "Wilma" - 1.653" (42mm)
Aria A-200 - 1.44" (36.6mm)
Aria Rock 'n' Roller 4001 - 1.59" (40.5mm)
Aria SB700 - 1.811" (46mm)
Aslin Dane Jazz Copy - 1.62" (41.3mm)
BC Rich Warlock Platinum Series - 1.65" (42mm)
Carvin LB70 - 1.54" (39.1mm)
Cort C4H (<2009) - 1.57" (40mm)
Cort C4H (>2010) - 1.5" (38mm)
Danelectro 63 RI (MIK) - 1.625" (41.3mm)
Dean Edge 4 (year unknown, made in Korea) - 1,614" (41mm)
Dean USA Hillsboro - 1.5" (38mm)
Eastwood Classic 4 - 1.5" (38mm)
Eastwood HiFlyer - 1.86" (47mm)
EBMM Bongo 4 - 1.625" (41.3 mm)
EBMM Caprice - 1.5" (38mm)
EBMM Cutlass: 1.625" (41.3 mm)
EBMM Ray 34 - 1.69" (43mm)
EBMM Sig.4 - 1.5" (38mm)
EBMM Sterling - 1.5" (38mm)
EBMM Stingray - 1.625" (41.3mm)
EBMM StingRay (1995) - 1.69" (42.9mm)
EBMM Stingray SLO - 1.5" (38mm)
EPI LTD Explorer = 1.662" (42.2mm)
ESP LTD Viper 254 - 1.574" (40mm)
Epiphone EB-0 - 1.5" (38mm)
Epiphone Jack Casady Signature - 1.65" (42mm)
Epiphone Thunderbird IV - 1.73" (43.9mm)
Epiphone Thunderbird pro-IV - 1.5" (38mm)
Epiphone Thunderbird (all 4 strings) - 1.5" (38mm)
Epiphone Toby Deluxe IV - 1.68" (42.67mm)
Epiphone Toby STandard IV - 1.68" (42.67mm)
ESP B-4 - 1.57" (40mm)
ESP D-4 - 1.57" (40mm)
ESP LTD B-154DX - 1.57" (40mm)
ESP LTD B204SM - 1.57" (40mm)
ESP LTD B-4E - 1.65" (42mm)
ESP LTD EC-104 - 1.57" (40mm)
ESP LTD F-414FM - 1.65" (42mm)
ESP LTD FB-4 Frank Bello - 1.65" (42mm)
ESP LTD GC-4 - 1.57" (40mm)
ESP LTD PT-4 Pancho Tomaseli - 1.77" (45mm)
ESP LTD Vintage-204 - 1.65" (42mm)
Faith Titan Neptune ABG - 1.673" (42.5mm)
Fender 56 Precision - 1.73" (43.9mm)
Fender 59 Precision - 1.71" (43.5mm)
Fender 60 Classic Jazz - 1.5" (38mm)
Fender 62RI Jazz - 1.5" (38mm)
Fender 64 Jazz - 1.5" (38mm)
Fender 67 Precision - 1.625" (41mm)
Fender 68 Telecaster - 1.75" (44.5mm)
Fender 69 Telecaster - 1.81" (45.9mm)
Fender 70 Classic Jazz - 1.5" (38mm)
Fender 70s Precision - 1.62" (41.3mm)
Fender 73 Precision (B Neck) - 1.64" (41.7mm)
Fender 82 Fullerton 57 Precision RI - 1.78" (45.2mm)
Fender '82 MIA Bullet B30 - 1.625" (41.3mm)
Fender Aerodyne Jazz - 1.5" (38mm)
Fender American Deluxe Jazz - 1.5" (38mm)
Fender American Deluxe P-Bass - 1.62" (41.3mm)
Fender American Hot Rod Precision '99 - 1.644" (41.8mm)
Fender American Special Jazz - 1.5" (38mm)
Fender American Special P-Bass - 1.69" (43mm)
Fender American Standard (1st version) '88-'94 - 1.5" (38mm)
Fender Antigua Precision - 1.62" (41.3mm)
Fender AVRI '57 & '62 P-bass - 1.75" (44.5mm)
Fender BG29 Bass - 1,70" (43.2mm)
Fender Blacktop Jazz - 1.5" (38mm)
Fender Blacktop Precision - 1.62" (41.3mm)
Fender Cabronita Precision (MIM) = 1.65” (42mm)
Fender Coronado (New) - 1.625" (41.3 mm)
Fender Coronado (vintage) - 1.5" (38mm)
Fender Custom Shop '59 NOS P - 1.75" (44.5mm)
Fender Custom Shop '64 Jazz Bass (NOS) - 1.5" (38mm)
Fender Custom Shop Jazz - 1.5" (38mm)
Fender Dimension - 1.5625" (39.6mm)
Fender Duff McKagan P-Bass - 1.62" (41.3mm)
Fender FR 51 Resonator Bass - 1.69" (43mm)
Fender Geddy Lee Jazz Bass (CIJ) - 1.5" (38mm)
Fender Geddy Lee USA Jazz = 1.55" (39.4mm)
Fender HM - 1.5" (38mm)
Fender Jazz Bass (original) - 1.437" (36.5mm)
Fender Jazz Plus '90-'94 - 1.5" (38mm)
Fender Jazz Special (mid 80's MIJ) - 1.5" (38mm)
Fender Jazz Special (1987) - 1.528" (38.8mm)
Fender Japan PJM-65R "Jazz Special" (1985) - 1.515" (38.5mm)
Fender Kingman AB - 1.5" (38mm)
Fender Limited Edition American PJ (2016 Magnificent 7) - 1.52" (38mm)
Fender Limited Geddy Lee 1972 Jazz - 1.5" (38mm)
Fender Limited Gold Top Dusty Hill Precision - 1.5" (38mm)
Fender Mark Hoppus Jazz - 1.62" (41.3mm)
Fender Mike Dirnt Road Worn Precision - 1.59" (40.4mm)
Fender Modern Player Dimension - 1.5" (38mm)
Fender Modern Player Jaguar - 1.5" (38mm)
Fender Modern Player Jazz - 1.5" (38mm)
Fender Modern Player Jazz Satin - 1.5" (38mm)
Fender Modern Player Tele Bass - 1.62" (41.3mm)
Fender Musicmaster Bass (1st version) - 1.625" (41.3mm)
Fender Musicmaster Bass 1976 - 1.59" (40.4mm)
Fender Mustang Bass RI MIJ 2006 - 1.5" (38mm)
Fender Precision Bass Special Deluxe Series - 1.5" (38mm)
Fender Precision Elite - 1.75" (44.5mm)
Fender Precision LYTE Deluxe - 1.50" (38mm)
Fender Reggie Hamilton Jazz - 1.5" (38mm)
Fender Road Worn 50 P-Bass - 1.75" (44.5mm)
Fender Roger Waters Precision - 1.75" (44.5mm)
Fender Sean Hurley Signature 1961 Precision - 1.75" (44.45mm)
Fender Select Jazz - 1.5" (38mm)
Fender Select Precision - 1.62" (41.3mm)
Fender Standard Jazz - 1.5" (38mm)
Fender Starcaster (New) - 1.625" (41.3mm)
Fender Steve Harris P-Bass - 1.75" (44.5mm)
Fender Telecaster Bass - 1.75" (44.5mm)
Fender Troy Sanders Jaguar - 1.5" (38mm)
Fender Vintage Hot Rod '60s Precision - 1.625" (41.3mm)
Fender Vintage Hot Rod '70s Jazz - 1.5" (38mm)
G&L 2012 Special M-2000 - 1.75" (44.5mm)
G&L Asat Semi Hollow - 1.5" (38mm)
G&L L1K '81 - 1.703" (43.3mm)
G&L L1000 2014 - 1.709" (43.4mm)
G&L L-2000 - 1.79" (45.5mm)
G&L SB-2T '14 (#7 neck) - 1.718" (43.6mm)
G&L Tribute L-2000 - 1.75" (44.5mm)
G&L Tribute L2000 (2012/13) - 1.692" (43mm)
G&L Tribute JB-2 - 1.5" (38mm)
G&L Tribute SB-2 - 1.5" (38mm)
Gibson EB-2 (vintage) - 1.60" (42mm)
Gibson EB-3 (1965) - 1.69" (43mm)
Gibson EB-3 (1973) - 1.562" (39.7mm)
Gibson Les Paul Oversized - 1.6" (40.6mm)
Gibson SG-Bass - 1.60" (42mm)
Godin Shifter Bass - 1.5" (38,1mm)
Gretsch G2202 Junior Jet - 1.625" (41.3mm)
Gretsch G5440LSB Electromatic - 1.69" (43mm)
Gretsch White Falcon - 1.28" (32.5mm)
Guild Starfire Reissue - 1.5" (38mm)
Hamer Cruise Bass (Slammer Series, 1st generation MiK) - 1.5" (38mm)
Hamer US Cruise - 1.456" (37mm)
Harley Benton HBZ-2004 - 1.57" (40mm)
Harley Benton JB-20 Standard - 1.5" (38mm)
Harley Benton PB-20 - 1.65" (42mm)
Harley Benton PB-50 - 1.65" (42mm)
Harley Benton PJ-4 Deluxe - 1.65" (42mm)
Harmony (unknown model 1991) - 1.65" (42mm)
Herby Custom Bass (MIJ. Ric copy 60's/70's) - 1.662" (42.2mm)
Hohner HAB-50 PS ABG - 1.668" (42.4mm)
Höfner 182 - 1.808" (45.9mm)
Hofner 500/1 - 1.65" (42mm)
Hofner Ignition Club - 1.531" (38.9mm)
Hofner Shorty - 1.69" (43mm)
Hondo Longhorn 1181 - 1.5" (38mm)
Ibanez AEB10 - 1.687" (42.84mm)
Ibanez AFB200 - 1.625" (41.3mm)
Ibanez AGB140 - 1.533" (39.4mm)
Ibanez Artcore AGB-200 Shortscale (2011) – 1.65” (42mm)
Ibanez EXB404 - 1.56" (39.6mm)
Ibanez GATK20 (2010-2011) - 1.673" (42.5mm)
Ibanez GSR200fm - 1.5625" (39.7mm)
Ibanez GSRM20 Mikro Bass - 1.5" (38mm)
Ibanez Iceman ICB-200 (Korea, 2004 approx) - 1.574" (40mm)
Ibanez Musician MC-924 (1980) – 1.65” (42mm)
Ibanez Musician MC-940 (1982) – 1.614” (41mm)
Ibanez RB850 (1985) - 1.585" (40.33mm)
Ibanez Roadbass RD828 (1991 approx made in Japan) - 1.594" (40.5mm)
Ibanez Roadstar II RB-920 (1983) – 1.575” (40mm)
Ibanez Roadster RS-824 (1981) – 1.594” (40.5mm)
Ibanez Roadster RS-940 (1980) – 1.65” (42mm)
Ibanez SR300 (2010) - 1.5” (38mm)
Ibanez SR4 - 1.5" (38mm)
Ibanez SR500 (2009) - 1.437" (36.5mm)
Ibanez SR500 (2012 approx.) - 1.5" (38mm)
Ibanez SRA500/SRA550 - 1.5" (38mm)
Ibanez SR600 - 1.5" (38mm)
Jack & Danny Jazz Bass - 1.5" (38mm)
Jackson C20 - 1.625" (41.3mm)
Johnson JG-622-E Acoustic (China) - 1.73" (44mm)
Jolana Diamant (Zech. LP) - 1.789" (45.7mm)
Lakland 44-64 Custom - 1.5" (38mm)
Lakland Skyline 44-01 - 1.65" (42mm)
Lakland USA Duck Dunn - 1.5" (38mm)
Maruszczyk Elwood Absolution 4 - 1.574" (40mm)
Mighty mite Jazz replacement neck (maple fingerboard) - 1,5" (38mm)
Mighty mite Precision replacement neck (maple fingerboard) - 1.62" (41,3mm)
Mike Lull P4 w/Jazz neck - 1.5" (38mm)
MTD Kingston Heir - 1.56" (39.6mm)
OLP MM2 (3rd generation, I believe) - 1.69" (43mm)
Ovation Magnum 1 - 1.64" (41.6mm)
Peavey Forum P/J (1994) - 1.5" (38.1mm)
Peavey Foundation (1986) - 1.5" (38.1mm)
Peavey Foundation (1991 & 1992) = 1.5" (38mm)
Peavey Fury (1983 - slanted SF) - 1.75" (44.5mm)
Peavey Fury (1987) = 1.5" (38mm)
Peavey Fury (1990 - P) - 1.5" (38.1mm)
Peavey Fury (1991 & 1992) = 1.5" (38mm)
Peavey Milestone III Jazz Bass - 1.5" (38mm)
Peavey Milestone IV P Bass - 1.46" (37mm)
Peavey Millenium BXP Jazz - 1.5" (38mm)
Peavey Patriot (1985) - 1.6875" (42.86mm)
Peavey Patriot (1987) = 1.5" (38mm)
Peavey RJ-IV (1991) - 1.6" (40.6mm)
Peavey Sarzo (US - 1991) - 1.625" (41.3mm)
Peavey T-20 (1982) - 1.6875" (42.86mm)
Peavey T-40 (1979) - 1.6875" (42.86mm)
Peavey Unity (1991 Koa P/J) - 1.6" (40.6mm)
PRS #11 - 1.692" (43mm)
Rickenbacker 4001 (1979) - 1.71" (43.5mm)
Rickenbacker 4001 (1979) - 1.69" (43mm)
Rickenbacker 4001 (March 1973) - 1.625" (41.3mm)
Rickenbacker 4001V63 (April 1998) - 1.718" (43.6mm)
Rickenbacker 4003FL (1985) - 1.625" (41.275mm)
Rickenbacker 4004 Laredo (NAMM Show instrument-December 2011) - 1.687" (42.8mm)
Rick Turner Renaissance RB4FL (2005-NAMM Show instrument) - 1.5" (38mm)
Ritter R8 (Vintage 4) - 1.535" (39mm)
Rob Allen Mouse - 1.653" (42mm)
Roscoe Custom "Birdie" - 1.653" (42mm)
Roscoe Custom "Bucky" - 1.811" (46mm)
Sadowsky Metro RV4-WL - 1.45" (37mm)
Sadowsky NYC J4 - 1.5" (38mm)
Sadowsky NYC Will Lee - 1.45" (37mm)
Steinberger Synapse XS1-FPA 4-string - 1.534" (38.98mm) (at zero fret)
Schecter Raiden Special 4 - 1.653” (42mm)
Schecter Stiletto Extreme 4 = 1.5" (38mm)
Sire M3 = 1.5" (38mm)
Spector Forte-4 - 1.61" (41mm)
Spector Legend 4 (1st Gen.) - 1.565" (39.75mm)
Spector Legend CLS - 1.5625" (39.7mm)
Spector Legend NS-2 - 1.5" (38mm)
Spector NS-2JA-R - 1.65" (42mm)
Squier Affinity Jazz - 1.5" (38mm)
Squier Affinity P-Bass - 1.62" (41.3mm)
Squier Bronco - 1.62" (41.3mm)
Squier Bronco (20th Anniversary Model) - 1.614" (41mm)
Squier Classic Vibe Jazz - 1.5" (38mm)
Squier Classic Vibe P-Bass 50 - 1.65" (42mm)
Squier Classic Vibe 60s P-Bass - 1.62" (41.3mm)
Squier Classic Vibe 70s P (2015 China) 1.61" (41mm)
Squier Dimension - 1.57" (40mm)
Squier Jaguar Short Scale - 1.5" (38mm)
Squier Matt Freeman P-Bass - 1.65" (42mm)
Squier Mike Dirnt Precision - 1.65" (42mm)
Squier Mikey Way Mustang - 1.5" (38mm)
Squier Pro Tone Precision Bass - 1.5" (38mm)
Squier Troy Sanders Jaguar - 1.5" (38mm)
Squier Vintage Modified Cabronita Precision Bass - 1.625" (41.3mm)
Squier Vintage Modified Fretless Jazz - 1.5" (38mm)
Squier Vintage Modified Jaguar "Standard" - 1.5" (38mm)
Squier Vintage Modified Jazz - 1.5" (38mm)
Squier Vintage Modified Jazz '70S - 1.5" (38mm)
Squier Vintage Modified Jazz '77 - 1.5" (38mm)
Squier Vintage Modified Precision - 1.62" (41.1mm)
Squier Vintage Modified Precision Fretless - 1.625" (41.3mm)
Squier Vintage Modified Precision PJ - 1.625" (41.3mm)
Squier Vintage Modified PJ (2014 Indonesia) 1.61" (41mm) (measured by TBer)
Squier Vintage Modified Precision TB - 1.59" (40.5mm)
Squier Vintage Modified Telecaster - 1.732" (44mm)
Squier Vintage Modified Telecaster Bass IV - 1.7" (43.2 mm)
Steinberger XP2 '86 - 1.5" (38mm)
Sterling by Music Man Ray4 - 1.5" (38mm)
Sterling by Music Man SUB SB4 - 1.5" (38mm)
Stu Hamm Urge I (1985) - 1.614" (41mm)
Suhr Classic J - 1.5" (38mm)
SX SBG2 - 1.69" (43mm)
SX SWB1 - 1.5" (38mm)
SX Ursa 1 - 1.625" (42mm)
SX Ursa 1 - 1.687" (43mm)
Takamine B10 - 1.8125" (46mm)
Takamine EG512 - 1.6875" (43mm)
Traben Standard 4 - 1.5" (38mm)
Vantage VA-900B (1981) – 1.59” (40.5mm)
Vantage VA-900B/FL (1981) – 1.59” (40.5mm)
Viola Bass with Variax transplant - 1.712" 43.5mm
Wal Mk 1 Custom Series (Soft V Profile) - 1.625" (42mm)
Wal Pro Series (C Profile) - 1.6875" (43mm)
Warwick Alien - 1.535" (39mm)
Warwick Buzzard - 1.73" (44mm)
Warwick Corvette 4 = 1.5" (38mm)
Warwick Corvette 4 $$ = 1.5" (38mm)
Warwick Dolphin - 1.73" (44mm)
Warwick Rockbass COrvett Short Scale - 1.5" (38mm)
Warwick Streamer 4 = 1.5" (38mm)
Warwick Stryker - 1.73" (44mm)
Warwick "Other 4 Models" - 1.515" (38.5mm)
Warwick Thumb NT4 (2013) - 1.51" (38.4mm)
Washburn SHB40 = 1.65" (42mm)
Washburn T24 = 1.589" (40.4mm)
Yamaha Attitude Standard (1991) = 1.65” (42mm)
Yamaha BB404 - 1.5838" (40.48mm)
Yamaha BB Series (424 to 2024) - 1.57" (40mm)
Yamaha RBX170 = 1.57" (40mm)
Yamaha RBX300 (1990) - 1.57" (40mm)
Yamaha TRBX 504 - 1.5" (38mm)
Zon VB-4 (Vinny) - 1.532" (38.9mm)

5 STRINGS
Alembic Classic - 2.00" (50.8mm)
Alembic Comfort - 1.875" (47.6mm)
Carvin LB75 (1991) - 1.71" (43.5mm)
Conklin Groove Tools GT-5 - 1.751" (44.5mm)
Cort Action V - 1.77" (45mm)
Dean Sledgehammer 5 Ash – 1.75” (44.45mm)
Dingwall NG2 (at the centre of the fanned nut, perpendicular to the A string slot) - 1.82" (46.35mm)
EBMM Stingray 5 - 1.75" (44.45mm)
Epiphone Thunderbird (all 5 strings) 1.73" - (43.94mm)
ESP B55 - 1.692" (43mm)
ESP LTD B-1005 - 1.85" (47mm)
ESP LTD B-105 - 1.77" (45mm)
ESP LTD B-155DX - 1.77" (45mm)
ESP LTD B-335 - 1.77" (45mm)
ESP LTD B-5 JR Junior Black - 1.625" (41.3mm)
ESP LTD B205SM - 1.77" (45mm)
ESP D5 - 1.771" (45mm)
ESP LTD F-105 - 1.77" (45mm)
ESP LTD F-5E - 1.85" (47mm)
ESP Surveyor 5 - 1.5" (38mm)
Fender American Deluxe Jazz V - 1.875" (47.6mm)
Fender Am Std Dimension - 1.75" (44.45mm)
Fender Modern Player Jazz V Satin - 1.875" (47.6mm)
Fender Standard Jazz V - 1.85" (47mm)
G&L L-2500 - 1.75" (44.5mm)
G&L Tribute L-2500 - 1.75" (44.5mm)
Harley Benton B-500 Modern Series - 1.77" (45mm)
Harley Benton HBZ-2005 - 1.77" (45mm)
Harley Benton PJ-5 Deluxe - 1.77 "(45mm)
Ibanez ATK305 ? 1.75? (44.5mm)
Ibanez BTB 675 - 1.85" (47mm)
Ibanez EX (1994) - 1.76" (44.7mm)
Ibanez Gary Willis Signature GWB1 - 1.75" (44.5mm)
Ibanez Gary Willis Signature GWB2 - 1.75" (44.5mm)
Ibanez GSRM25 Mikro Bass 5 - 1.77" (45mm)
Ibanez Sr705 2014 - 1.693" (43mm)
Ibanez SR1205-VNF - 1.77" (45mm)
Ibanez SR5 - 1.77" (45mm)
Lakland 55-94 - 1.80" (45.7mm)
Lightwave Saber SL 5 (fretted) ? 1.75? (44.5mm)
Martin Keith Elfin 5 fretless (2010-NAMM Show instrument) - 1.875" (47.6mm)
Martin Keith Elfin 5 (2011) - 1.875" (47.6mm)
Modulus Bassstar - 1.75" (44.5mm)
Modulus Q5 - 1.85" (47mm)
Modulus Q5W19 - 1.90" (48.26mm)
Modulus Q5W21 - 2.00" (50.8mm)
MPG Level-5 Fretless - 1.81" (45.97mm)
Ritter Coda (Vintage 5) - 1.948" (49.5mm)
Ritter R8 (Vintage 5) - 1.948" (49.5mm)
Schecter Diamond Series Elite-5 - 1.79" (45.5mm)
Spector Coda-5DLX/XL - 1.87" (47.6mm)
Spector Coda Pro 5 - 1.75" (44.45mm)
Spector Core 5 - 1.75" (44.45mm)
Spector Euro5LX - 1.85" (46.99mm)
Spector Forte-5 - 1.81" (45.97mm)
Spector Legend Classic-5 - 1.75" (44.45mm)
Spector NS-5 - 1.80" (45.72mm)
Spector NS-5H2 (Wide-5 model) - 1.80" (45.72mm) or 1.88" (47.75mm)
Spector NS-5XL - 1.81" (45.97mm)
Spector Performer 5 - 1.75" (44.45mm)
Spector ReBop-5 - 1.81" (45.97mm)
Squier Affinity Jazz V - 1.87" (47.6mm)
Squier Deluxe Jazz V - 2" (51mm)
Squier Dimension - 1.75" (44.45mm)
Squier Standard P Bass Special 5 - 2.008" (51mm)
Squier Vintage Modified Jazz V - 1.87" (47.6mm)
Sterling by Music Man SUB - 1.77" (45mm)
Sterling by Music Man Ray5 - 1.77" (45mm)
Vintage Modified Precision V - 1.875" (47.6mm)
Steinberger Spirit 5 circa 2010, 1.75" (44.5mm)
Steinberger Synapse - 1.77" (44.96mm) @ 0 fret
Traben Array 5 - 1.78" (45.2mm)
Traben Array Limited - 1.78" (45.2mm)
Traben Chaos Core 5 - 1.78" (45.2mm)
Traben Standard 5 - 1.5" (38mm)
Wal 5-String Mark IIs - 1.85" (47mm)
Wal 5-String Mark IIIs - 1.85" (47mm)
Warwick "All 5 Models" - 1.771" (45mm) or 1.85" (47mm)
Yamaha BB1025 – 1.692” (43mm)
Yamaha BB415 - 1.653" (42mm)
Yamaha BBNE1/BBEAST - 1.875" (47.62mm)
Yamaha TRBX 505 - 1.692" (43mm)
Zon 5/1 (circa 1996) - 1.85" (47mm)

6 STRINGS
Brice Z6 – 2.126” (54mm)
Carvin LB76 - 2.02" (51.3mm)
Harley Benton HBB600TBK - 2.175" (55.2mm)
Harley Benton HBB6000 - 2.095" (53.2mm)
Ibanez BTB 456 – 2.126” (54mm)
Roscoe 3006 - 2.150" (54.61mm)
Squier Vintage Modified Bass VI - 1.65" (42mm)
Tune TWB63WN - 2.291" (58.2mm)
Warwick "All 6 Models" - 2.047" (52mm) or 2.165" (55mm)
Yamaha RBX6JM (2000 mk i) -1.968" 50mm
Yamaha TRB 6II – 2.047” (52mm)
Yamaha TRB JP2 – 2.205” (56mm)

7 STRINGS
Roscoe SKB 3007 - 2.470" (63.14mm)
Wolf WTHB-7W - 2.418" (61.4mm)
Zdressy Fretless (2016) - 2.36" (59.9mm)

8 STRINGS
Ibanez Musician MC-980 (1980) – 1.692” (43mm)
Rogue LX408 Custom - 1.771" (45mm)

  • Like
Reactions: DavesnothereCA, KeithAlanK, dxb and 2 others

Latest posts

Top Bottom
Back
