Anyone with a late 2020 to 2021 NS2, i'd be grateful if you could share a picture of the pre-amp connections to pickups or confirm white/black/red from top to bottom on the p/u plugs.
I'm only able to find the wire diagram for the previous model Haz and it's completely different.
Just by looking at it i'm guessing the pickup plug harnesses will be white/black/red in that order from top to bottom when plugged in.
bottom pins on pickup plugs on circuit board go to +battery terminal, so im guessing red.
middle pins on pickup plugs on circuit board go to rings around the pots, so im guessing black for ground.
top pins on pickup plugs on circuit board go to P/U balance knob so im guessing white for hot signal?
Also, based off the earlier Haz the plug next to battery is for bridge p/u and top center plug to neck p/u?
Thanks everyone and here is a photo of what im working with.
I sourced the plugs from a molex retailer.
View attachment 4360750
