AMPEG SVT II CIRCUIT BOARD PHOTO?????????????????????????

[Bassholio]

Does anyone have a close-up photo of a 1991 SVT II (non Pro) power tube circuit board? I need the section where the 6 pin multi-connector goes.

The 1991 SVT II I bought had a 4 inch drywall screw rattling around inside when I got it. Turns out it shorted out a quarter size section of the PC board along with a few resistors and caps. I have the parts and a great picture of the backside of the PC board, but I need a picture of the component side to see where the traces on that side go to.
Thanks guys...

BTW - I have a first-born male to trade...

Thanks all



[rodl2005]

Ooooo No I don't, but I'll get U one if'n no-one else chimes in w/ one.

Rod



[KramerBassFan]

http://www.chambonino.com/work/ampeg/amp4.html



[anderbass]

Hey Bassholio, I think the pic below shows the area you wanted but I went ahead and uploaded all my SVT-II gut shot pics to this album for ya: http://s72.photobucket.com/albums/i172/Mybigpics/SVT-II/



[rodl2005]

Ha!! there U go!! hOW ARE u ANDERBASS?????? I just grabbed a Mesa WA scout. Damn lovely sound for a hybrid, Handy for my li'l blues gig. ONE LEAD to plug amp in
, one for the bass!!!!!!!!!!!! Hope U & yours R well mate.



[Bassholio]

Thanks Anderbass...that is the EXACT area I need a closeup of, and actually the area I'm trying to piece together is under that blob of silicone @ the mounting hole.

And to Rodl2005...if you can get that portion of the board i n a picture or closeup...that would make my millennium...

Thanks guys...



[anderbass]

Bassholio, Is my link working now?

Hey Rod, I'm doing good. Congrats on getting that Scout, I'd like to try one of those out some day.



[Bassholio]

Well after a long series of restorative, and repair work, my SVTII is up and running like the wind.
Played it this past weekend and I still can't get the grin off my face. I'm done with solid state...
To everyone, especially Anderbass, thanks muchly!!



[anderbass]

Hey yer welcome, glad you got-er going there.



[KramerBassFan]

I'm curious... how do you get a 4 inch drywall screw in an amp like that?



[Bassholio]

Kramer....
VERRRRY CAREFULLY.
haha
