Battery box options

[Fender597]

What battery box would be my best option to Install on a DIY Fender Jaguar bass? Building an active bass and looking for any input on make/model and most ideal location for wiring purposes.



[LoveThatBass]

I got tired of removing a screw down plate that only had room for one 9 volt battery and wanted to run a new preamp at 18volts. Someone posted a circuit in an external box that used a 9 or 18 volt Walwort to power the bass thru A stereo cable with TRS plugs and pass signal from bass to amp.Built my own. Works great



[Reedt2000]

Well, Fender puts it here:

There are battery boxes that don't require unscrewing to change the battery. They typically have little plastic clips that hold them closed which can break. A simple plate like Fender uses is pretty much guaranteed to work problem free



[Turnaround]

If you use a battery box, rather than just a rout with a cover, I would advise against those that pivot the battery out when you open the cover, like this:

I have had to repair or replace so many of them because the wires have broken off from flexing when the box is opened and closed. The ones I prefer are like this:

The contacts for the battery are fixed in place in the body of the box - no wire flexing when you open the case. Simpler, cheaper, and they don't require as deep a rout as the first kind.



[claudel]

If you use a battery box, rather than just a rout with a cover, I would advise against those that pivot the battery out when you open the cover, like this:

View attachment 3944717

I have had to repair or replace so many of them because the wires have broken off from flexing when the box is opened and closed. The ones I prefer are like this:

View attachment 3944756

The contacts for the battery are fixed in place in the body of the box - no wire flexing when you open the case. Simpler, cheaper, and they don't require as deep a rout as the first kind.

What brand is that?

Are they available in double for 18V?

I've had the issue you mentioned with Gotoh...

TIA



[Turnaround]

What brand is that?

Are they available in double for 18V?

I've had the issue you mentioned with Gotoh...

TIA

Fishman makes some:
https://www.musiciansfriend.com/accessories/fishman-fluence-9v-battery-box-for-powerbridge

Haven't seen a double in real life though. Saw one online from MEC but couldn't find it in North America.
MEC 50004 double battery box (18V)



[MrLenny1]

Cavity covers that use magnets instead of screws are
a nice setup.
