Double Bass Ideas for a Removable neck with Weight adustments

[rgarcia26]

Hi guys I have being repairing a Flat back for few months now, and I have to replace the neck block, and it occurrence to me that I could do a removable neck, but them It concurred to me also to make it with adjustable string height... something with some linear movement that I can adjust a little string height, and release the neck.



So far I am thinking on doing some kind of Screw Vise in a rail... to provide the movement.. what it bugs me a little, is that as the neck moves forward the neck joint being wider at the finger board and narrower at the bud, it wont have a tight fit, it may have to be an square joint?


Something based similar to this
Link Removed

From the guys that have done it before, there is any ideas experiences or may be considerations that you may want to share with me?

Thanks Cheers Ruben!!!



[T-Bird]

Hi.

Mine's been in the planning stages for ages and not even a single piece has been made, but the quick release I've planned to use is just a simple eccentric mechanism integrated into the tail piece/tail wire.
Pretty much the same as in a butterfly-latch of a road case.

Regards
Sam



[drurb]

I assume what is meant is adjustable string height, not weight. Upton has done this rather elegantly. The neck can be moved forward and back on what amounts to a worm gear. Check out their design.



[rgarcia26]

I assume what is meant is adjustable string height, not weight. Upton has done this rather elegantly. The neck can be moved forward and back on what amounts to a worm gear. Check out their design.

You are correct I totally used the wrong term is actually string height at the finger board, moving a neck a little forward or back.

I saw their video, but I couldn't see any details from it...

Thanks Drurb



[rgarcia26]

Something like this:
Link Removed

The fundamental problem of pushing forward or back the neck joint I think is the joint have to be square, otherwise I will not work.

I noticed that Jim Ham uses something like a Square Tenon if I am not mistaken, that's what I am trying to figured out.

Also how to fit this whole system correctly.



[powerbass]

I've wanted to modify my bass w/adjustability. my concern about your mechanism is that it is too busy, complicated and heavy. ideally the amount of movement is pretty small in order to deal w/seasonal changes. I recommend you look at what James Candino and Jim Hamm have done w/removable necks first



[rgarcia26]

Hi Powerbass, thanks for your feedback, I am actually trying to design something like J.Ham system, I am not aware of Jame's design, I don't know where to look to see it, I am really trying to make it as simple as possible, but I haven't got an easer and simpler answer to the problem.

How to convert rotary motion into linear motion?
-Simple, small, and easy? I am still working on it.

RG
