Need help with recording with DI on a Markbass amp

#21
matan326 said:
Right! So if I understand it right, would this cable be good to solve my problem?

https://www.amazon.com/Roland-210950099-RCC-10-TRXF-Interconnect-Cables/dp/B01CR114HW
Click to expand...
Well, as it is now, it is not correct! So needs to be addressed in any case.

My supposition is that all of the combined details will address the issue:

Correct XLR female to TRS male cable. (get a good one! the example you linked looks fine)
Switch set to Line (Solo)
Adjust the line signal at the amp (CMD 102) far right.
Adjust the gain on the Solo so it shows green (not red)

* Also check the GAIN on the input channel on your software DAW (recording software) Ableton?

How are you monitoring the instrument while recording? it's possible that the distortion is in the gain stages in the software....

I missed if you mention windows or mac

ex: Invalid Link Removed

Last edited:
As an Amazon Associate, TalkBass may receive commissions from qualifying purchases made via links on this site.
  • Like
Reactions: matan326
#22
/\/\3phist0 said:
Well, as it is now, it is not correct! So needs to be addressed in any case.

My supposition is that all of the combined details will address the issue:

Correct XLR female to TRS male cable. (get a good one! the example you linked looks fine)
Switch set to Line (Solo)
Adjust the line signal at the amp (CMD 102) far right.
Adjust the gain on the Solo so it shows green (not red)

* Also check the GAIN on the input channel on your software DAW (recording software) Ableton?

How are you monitoring the instrument while recording? it's possible that the distortion is in the gain stages in the software....
Click to expand...
I've done all except to switch out the cable, so I'll get a new one and I'll see.

The gain in Cubase is completely fine, it's that no matter how low or high the gain is, the distorted noise is still there. (the bass signal is also there)

  • Like
Reactions: /\/\3phist0
#25
/\/\3phist0 said:
Cuebase: ASIO4ALL distorted sound
focusrite tips:
Invalid Link Removed
Invalid Link Removed
Glitchy audio troubleshooting

If you continue to experience clicks/pops/distorted audio after following the steps above then you may be experiencing an issue relating to DPC Latency. If that's the case, please see our Invalid Link Removed.
Invalid Link Removed
Click to expand...
Well the thing is, the distorted noise happens only when I try to record with line out in the amp. Everything is alright when I go straight into the interface

#26
matan326 said:
Well the thing is, the distorted noise happens only when I try to record with line out in the amp. Everything is alright when I go straight into the interface
Click to expand...
According to your manual, you can't use the xlr input because its only mic level. So, why use an altered cable at all? Just run a standard quarter inch instrument cable from the effect send on your amp, into input 2. Problem solved.

Last edited:
  • Like
Reactions: agedhorse
#28
agedhorse said:
Why can’t you set your amp’s DI output to mic level?

That plus an XLR-XLR cable is the solution intended by both the amp manufacturer and ivy interface manufacturer.
Click to expand...
I looked at the manual that was posted for that amp, and I didn't see a pad or attenuation of any kind on his di out. It says simply "line out" in the manual. My amps (except one) all have a -40 db pad switch on them. But, I have noticed that if I send a pre eq signal, my output is sky rocketed compared to my post eq. So, I hit the switch if I'm running pre, flip it off if I'm running post. That could be a similar thing on his too. Maybe setting the amp flat, and running post eq could drop that gain on his DI? Whatever way his particular output and features work, running out the send will for sure work. An effects loop is designed to feed pedals. Know what I mean? Can't go wrong with that. Well...you'd think, I should say.

#29
@agedhorse The XLR is labeled as line out. On the amp and in the manual.

@JeezyMcNuggles
The line out has a control for line level on the face of the amp.
There is no provision or control to alter this signal type to MIC.
Using the effect send on these amps could work but is an unbalanced signal . This may be noisy.
For that matter, he could use the tuner out.

Last edited:
  • Like
Reactions: JeezyMcNuggles and Bass Jones
#31
Looking at the specs for the Sacrlett gen 2, there shouldn't be any problem using the line out into the mic input of the interface with the line output turned down some.

Here's from the interface manual:


This shows a maximum input level of +4dBu, and the amp has a maximum output level of +23dBu, so with the line output control turned down, this will reduce the MOL to an acceptable value.

I confirmed that the line output control will adjust the signal level at the DI output all the way from mic level to line level.

The solution you need is already provided with the equipment you have and the XLR-XLR cable.

  • Like
Reactions: /\/\3phist0, MCF, Zbysek and 2 others
#32
agedhorse said:
Looking at the specs for the Sacrlett gen 2, there shouldn't be any problem using the line out into the mic input of the interface with the line output turned down some.

Here's from the interface manual:
View attachment 4151443

This shows a maximum input level of +4dBu, and the amp has a maximum output level of +23dBu, so with the line output control turned down, this will reduce the MOL to an acceptable value.

I confirmed that the line output control will adjust the signal level at the DI output all the way from mic level to line level.

The solution you need is already provided with the equipment you have and the XLR-XLR cable.
Click to expand...
Thank you so much. Do you also reckon that plugging into the instrument/line input with an XLR-TRS cable will work? Because when I tried the recording, I was plugging in with a TS cable and not TSR.

#33
I don't know how the instrument input handles a TRS connector and what actually happens when the ring is not connected to the ground.

Just use a standard mic cable (XLR-XLR) and turn the line output down. If that doesn't work, one of the 2 pieces are broken or defective.

  • Like
Reactions: JeezyMcNuggles, MCF, Zbysek and 2 others
#39
JeezyMcNuggles said:
No, your di states thst it's line level though. With no switching capabilities. Have you tried switching between post and pre eq though? I said earlier that my amp has a pretty drastic increase in levels between the two options. Post being much tamer.
Click to expand...
There's a level control for the DI output that will reduce the line level to zero if desired. It doesn't need switching because it's variable.

  • Like
Reactions: Matty Koff
