Ottobasskirk said:
I have some knowledge of electronics, but before I can even start to do some trouble shooting on this thing, I would need first a schematic of the circuit board, and know what the hell all the knobs and switches do! Does anybody know what the knobs and switches actually do? I have searched for some schematics and have only found some very basic ones that don't match what I have. Here are some photos of my axe
Click to expand...

It looks like the same switch and knob setup (AND EVERYTHING ELSE) as a Thunder II (82-83).There is wiring diagrams for a Thunder two which even include a picture of the circuit board. If this isn't entirely the same electronics I would be shocked Invalid Link Removed
Invalid Link Removed

Last edited:
#405
DanAdams said:
It looks like the same switch and knob setup (AND EVERYTHING ELSE) as a Thunder II (82-83).There is wiring diagrams for a Thunder two which even include a picture of the circuit board. If this isn't entirely the same electronics I would be shocked Invalid Link Removed
Invalid Link Removed
Click to expand...
Thanks, I finally figured that out. I had to look at my circuit board and determined this to be the case. I appreciate your response. I think my bridge pick up needs to be rewired.

#407
mcbrat said:
proxy.php?image=http%3A%2F%2Fwww.rivercityamps.com%2Felectraforumimages%2Fimages%2Fgreen-x640-1.png
Click to expand...


I picked up one of these that looks exactly like this except it's glossy black. It came with a fretted and fretless neck. I wasn't sure what model it was since it doesn't seem to have any markings to tell you. I'd like to play it more but I'm having some issues to work out before I can. I made a thread about it here.

#408
BonesawMcgraw13 said:
I picked up one of these that looks exactly like this except it's glossy black. It came with a fretted and fretless neck. I wasn't sure what model it was since it doesn't seem to have any markings to tell you. I'd like to play it more but I'm having some issues to work out before I can. I made a thread about it here.
Click to expand...
Take a picture of the control cavity if you can. I know posting pics here can be a drag, sign up for a free photobucket account if you need to, it makes sharing pics easy. Do you have a soldering iron and a multimeter?
You can get a whole setup of both for around $30 at Amazon.

And are you sure it's passive? that's a lot of switches for a passive bass with just a split coil and a single coil.

Dang, free Westone with dual necks! you scored big time

#410
DanAdams said:
Take a picture of the control cavity if you can.
Click to expand...
I took a few pics and will post Monday when I have access to a computer again.

I don't think it was passive originally. The guy I got it from rewired some things. All of the switches have been disconnected. The only things still connected are the pots and jack which are connected to wires I assume are going to the pickups. The pickups are emg so Im sure they aren't the original pickups.

Yea it was a sweet deal. Now if only I get the thing to work.

#411
BonesawMcgraw13 said:
I took a few pics and will post Monday when I have access to a computer again.

I don't think it was passive originally. The guy I got it from rewired some things. All of the switches have been disconnected. The only things still connected are the pots and jack which are connected to wires I assume are going to the pickups. The pickups are emg so Im sure they aren't the original pickups.

Yea it was a sweet deal. Now if only I get the thing to work.
Click to expand...
gotcha. it was most likely a passive bass with an odd switchable active bass boost thing. my thunder III has that active thing, I prefer to play it passively.
if someone tried to ad active pickups to the existing controls it may just explain your weak output.
I'll be curious to see the pics. I dislike EMGs, but a lot of folks like them. I have EMGs in my Thunder I. I can't wait to tear them out.

#412
#413
BonesawMcgraw13 said:
View media item 9198View media item 9197View media item 9196View media item 9195View media item 9194View media item 9193Here's the pics from the westone I picked up. I'm not sure how much you can tell. I know there's a battery which would imply it's active but I tried changing it and nothing happened. There's 2 wires from the battery one goes to I assume the pickups and the other to the jack. It may just be being used to complete the circuit.
Click to expand...

I see pic information in reply mode but nothing in you sent post...

#418
It sounds like someone threw in some EMGs without changing anything else. could be an easy fix... but with two batteries, one for the EMGs and one for the westone circuit? Or forget the Westone circuit and put in some new 35k or whatever pots EMGs need, or I'm about to sell an EMG BTS EQ preamp system if you want to go that route, but I would suggest buying a set of passive P and J pickups.
I bought these cheap ass p bass pickups and I think they're awesome. $6.86!!! no joke http://smile.amazon.com/String-Nois...8&qid=1459222013&sr=8-1&keywords=bass+pickups
