Hi Guys,
This is going to be a bit long so bear with me. The Landmark has never been used. It was given to Ged before the start of the Vapor Trails tour along with some cabs, from Tech 21. I threw the amp in the rack thinking he my want to try it. You must remember, this was before Ged decided to switch to "Maytag's" for his backline. I have left it in there as at the time, I didn't need the rack space and as Tech 21 has always been great to me, I thought it might help them with a bit of exposure. That will be coming out out for this tour in 2008. I need the space! Before I go into below, I just want to mention their are many spares for gear mentioned!
Here is the signal routing in detail: This is going to be interesting to explain this properly. We use two Samson UR-5D wireless units. They are single rack mount dual wireless receivers. Each channel has their own dedicated output. Signal routing for hooking up, all of these pieces are unbalanced 1/4" jacks. Audio obviously takes XLR line level outs, from the outboard gear, not the wireless!
The outputs from the Samson's (4 in all) now go to a Kittyhawk Midi Looper. Most of you will probably not be familiar to the Kittyhawk products. I came across Kittyhawk products when I worked for the Scorpions in the 90's. It was, and still may be, a small German company that made loopers, midi switchers, amps, etc. Well made products and a very unique individual, Gundolf, who made these products! I thought they sounded good, worked well and very reliable.
This Kittyhawk, as the name implies, was primarily made to midi switch to different effects. I don't use the midi function, no need. I use it basically as multi-channel "A/B" box, rack-mounted! This unit has six separate channels. I take the separate wireless outputs to each individual channel input on the Kittyhawk. The Kittyhawk has a MAIN OUTPUT, for all channels.
The Kittyhawk has individual switches on the front to turn each channel on and off, as desired. As Ged switches to a different bass, I just hit the corresponding switch on the Kittyhawk to activate that bass. This gives me the luxury to know that as he is playing one bass, I can unplug, tune another bass, without sending any 'popping' noise to to audio as that particular channel of the wireless is muted! This means not having to mute, turn off transmitter, or turn down the output volume of the wireless receiver.
Okay, I'm going to stop here as I want to hear your feedback as I to make I'm making sense to everyone. Don't get me wrong, I HAVE never gone into this much detail in writing! I'm use to giving someone details when they are standing next to the rig. It's a little easier to show then write about.
