is this a set neck or neck thru?

Discussion in 'Luthier's Corner' started by woaheasylang, Mar 8, 2010.


  1. woaheasylang

    woaheasylang

    Feb 11, 2009
    can someone please explain to me if this is a set neck or neck thru and how it is a set neck or neck thru because i dont see where exactly it "sets" in nor do i see the neck going all the way through. sorry for the noob question..

    http://fodera.com/images/monarch_series_23.jpg

  2. iriegnome

    iriegnome Bassstar style Supporting Member

    Nov 23, 2001
    Kenosha, WI 53140
    It looks (the picture is tiny) like a set neck. Neck through's bring the neck from the headstock all the way to the strap button! This one looks like the body is seperate from the neck, but glued or joined instead of using a neck plate and screws.

  3. Rickett Customs

    Rickett Customs

    Jul 30, 2007
    Southern Maryland
    Luthier: Rickett Customs...........www.rickettcustomguitars.com
    Pic is too small..

  4. woaheasylang

    woaheasylang

    Feb 11, 2009
  5. mikeyswood

    mikeyswood Inactive

    Jul 22, 2007
    Cincinnati OH
    Luthier of Michael Wayne Instruments
    Fodera Monarchs are set-necks; there is the potential of nt.

  6. FunkMetalBass

    FunkMetalBass

    Aug 5, 2005
    Phoenix, Arizona 85029
    Endorsing Artist: J.C. Basses
    It could be a neck-through with a top and bottom cap, but the bottom appears to be rather thick, so I'm thinking it's glued into a routed channel.

    This would be more aptly titled a set-through, because the neck extends at least partially through the body, but not entirely.

  7. Rickett Customs

    Rickett Customs

    Jul 30, 2007
    Southern Maryland
    Luthier: Rickett Customs...........www.rickettcustomguitars.com
    yes, I'd say SN. Mainly because the body is 2 pieces, joined in the center (No wings). However, you can find a NT in this similar look, but more likely than none, they're capped on the back.... A set neck can go a little further into the body, than a bolt on (More gluing surface), generally to the neck pickup. Making a NT in the fashion of the pic, will require more work to do.

  8. woaheasylang

    woaheasylang

    Feb 11, 2009
    also, if you guys noticed, there isnt a slot for where you could adjust the truss rod..

  9. BluesWalker

    BluesWalker Supporting Member

    Jun 17, 2008
    San Diego
    I guess could write or call Fedora to get a definitive answer.

  10. rodneyat

    rodneyat

    Apr 12, 2007
    Atlanta, GA
    What does that have to do with set neck or neck through? Unless I am missing something, that does not matter. Fodera Monarchs have the truss rod adjustment on the headstock, btw. And have a set neck or dovetail design. The only Fodera with the adjustment at the bass of the neck is the NYC, as far as I know.

  11. Rickett Customs

    Rickett Customs

    Jul 30, 2007
    Southern Maryland
    Luthier: Rickett Customs...........www.rickettcustomguitars.com
    Headstock.

  12. FunkMetalBass

    FunkMetalBass

    Aug 5, 2005
    Phoenix, Arizona 85029
    Endorsing Artist: J.C. Basses
    Hence why calling it a ST [set-through] would probably be the most applicable term. Set necks are set on the very end, through necks extend through the bass. This is the best of both worlds and is common in a few ESP models (they refer to it as ST construction).


    Lollerskates. :p

    Fodera:
    [​IMG]


    Fedora:

  13. gregwatts2008

    gregwatts2008 Supporting Member

    Nov 30, 2008
    Jupiter, Florida
    This is a neckthru.....

  14. woaheasylang

    woaheasylang

    Feb 11, 2009
    i didnt know that.. almost all of the set neck constructions ive seen have the truss rod at the pocket where the neck sets into.. now i know better. thanks for the information :)

  15. mikeyswood

    mikeyswood Inactive

    Jul 22, 2007
    Cincinnati OH
    Luthier of Michael Wayne Instruments
    Spelling Win!

  16. Beej

    Beej

    Feb 10, 2007
    Vancouver Island
    From the Fodera Monarch website:

  17. mhduffl

    mhduffl

    Nov 27, 2008
    Hong Kong
    It's set neck,
    I have one Fodera Monarch with this neck joint.
    Fodera craftmanship is second to none.....
    Don't just look at the pics, but to get one to play....haha
