Jazz bass control cavity cover replacement

Discussion in 'Hardware, Setup & Repair [BG]' started by Charlzm, Sep 8, 2017.

  1. Charlzm

    Charlzm Guest

    Mar 25, 2011
    I am building a Frankenbass with the body of a Squier Jazz as the foundation. I want to put a pre-amp in, which is causing me a little anxiety, since the pots that are already wired into the pre-amp harness are from a Warwick. They don't fit through the holes in the original chrome control cavity cover.

    I could try to route out the metal piece, but since these parts are relatively inexpensive, I figured I would just buy a new control plate with openings sized for the Warwick pots.

    However... I either can't find can't find any measurements listed for replacement plates (which leads me to assume they are identical to the Fender/Squier standard) or the size listed is the same as what's on there now.

    Anybody know of a source for J-Bass control plates with alternative control hole sizes?

  2. Charlzm

    Charlzm Guest

    Mar 25, 2011
  3. testing1two

    testing1two Supporting Member

    Feb 25, 2009
    Southern California
    You can enlarge those holes with a reamer or a 3/8" drill bit if you're careful. It's standard practice when replacing pots on Squiers.

    Warhawk and Lownote38 like this.
  4. Charlzm

    Charlzm Guest

    Mar 25, 2011
    I had been hoping to avoid that since I'd have to buy/borrow the tool. But it's looking more and more as if that's how it's going to be.

  5. Gilmourisgod

    Gilmourisgod

    Jun 23, 2014
    Cape Cod MA
    If you dont have a drill, Get a small round file at the hardware store, 5 minutes work and Bob's Your Uncle.

    Warhawk likes this.
  6. Lownote38

    Lownote38

    Aug 8, 2013
    Nashville, TN
    The reamer is only a few dollars, and I purchased one for the very reason you need one. Since I got it, I've used it for a bunch of other projects. It's a good tool to have.

  7. Gilmourisgod

    Gilmourisgod

    Jun 23, 2014
    Cape Cod MA
    Do you remember where you got your reamer? I looked for one, all the ones I could find locally were slightly too small, I think they maxed out at 1/2", and I needed 9/16. All the larger ones I found online were pretty expensive.

  8. Lownote38

    Lownote38

    Aug 8, 2013
    Nashville, TN
    Home Depot. They had tons of them in different sizes. The one I got was to make a Japanese Fender control plate fit with normal sized CTS pots, and when I got the holes big enough, I still had plenty of room to go bigger. I asked a local repair person here what to do when I had to rebuild that wiring harness for a friend, and she showed me the reamer she used. I didn't want to use the mini pots that the MIJ Fender basses had at the time.

  9. Gilmourisgod

    Gilmourisgod

    Jun 23, 2014
    Cape Cod MA
    Dang! My local HD sucks, it's about half the size of most HD stores, their inventory is pretty thin. I know I looked there a while back. I don't see anything that looks like a traditional tapered Luthier's reamer, but they do have step drills graduated in 1/16ths like this one, which would have worked nicely widening my tuner holes to 9/16". Something like this might work for the OP. They have the advantage of being self-centering, but I'd still want to use a drill press through a metal control plate.
    Kawasaki Titanium Step Drill Bit-841344 - The Home Depot


    Attached Files:

    Charlzm likes this.
  10. Lownote38

    Lownote38

    Aug 8, 2013
    Nashville, TN
    Check the Home Depot website. If your local store doesn't have what you need, the website should, and you can order it.
