need help matching cabs

#21
It's ok to run it at lower impedances. Others have reported going hard at 2.7ohm no problem.
MarkA said:
Specifications (from the [Invalid or Expired Link Removed]):

Power Output:
225 watts-16 Ohms, 450 watts-8 ohms, 800-watts, 4 ohms (2 Ohm use possible, but may experience clipping at high volume.)

AC Power Req.:
100–240Vac, 50–60 Hz, 250 W typical, 1000W peak.

Signal Connections:
PASSIVE INPUT: ¼" mono (full gain), 2 meg
ACTIVE INPUT: ¼" mono (-10dB gain), 30K
LINE INPUT: XLR 10K balanced, 1V full scale.
LINE OUTPUT: XLR, quasi-balanced, 400 ohms, 1V full scale

Controls:
GAIN CONTROL MUTE BUTTON (with red warning LED)
DEPTH CONTROL (100Hz Hi-Q bass control)
CONTOUR CONTROL (Low-mid scoop, flat, treble cut)
MASTER CONTROL (adjusts peak power from 0 to 800W)
PILOT LIGHT (“winks” if the amplifier is driven into thermal limiting)

Speaker Connections:
4-8 ohms, 90V, 25A peak
Dual ¼” jacks, 8 ohms each
Speakon (2 wire) 4-8 ohms.

Headphone Out:
3.5mm mini-jack, 20 ohms per side, 2V peak.

Dimensions:
H x W x D 8.5”(218mm) x 7.5” (190mm) x 3” (76mm)

Weight:
3.7 lbs (2kg)

Approvals:
UL recognized, tested to conform to FCC/CE limits for Class B devices.
Click to expand...

#24
Skillet said:
You need Two 8 ohm cabs. 8 + 8 = 4.
Or one really loud 4 ohm cab.
Click to expand...
lol that's what i got, a really loud 4 ohm cab, after posting this thread we had an outside sound gig, in which i played the first set using my amp, the next band came up with a markbass 12 combo and 18" hartke extension speaker......we were scrambling to get him in the mix, the band after them used my cabinet.....That's when i realized......ta hell with totin' an extension cabinet....this f'r sounds sweet! it was 5 times as loud as the previous bassist and on half the power setting!

  • Like
Reactions: Skillet
#25
ok here goes,, y'all dont kill me, i did buy this used and I have all the markings off the cabinet... I know his history,,,but this thing is a beast
its the drb2460 4ohm 1000w model

okcrum






JRA said:
can you provide a link to that cabinet: not familiar! thanks.

a series cable/box will get you 8 ohms from two, 4-ohm cabinets.

-or-

as okcrum suggested: another amp slaved to your existing amp solves the problem, gives you a backup amp, and allows for all kinds of 'rig shaping' in the future. plus: it takes the impedance issue off the table in most cases.

-or-
many 15" drivers will be fine with a 2-12 (check specs/power ratings!). the idea that you can't pair a 15 with a 2-12, effectively, is false. it just depends on your choices!

good luck! :thumbsup:



sort of depends on the drivers being used, doesn't it? ;)
Click to expand...

  • Like
Reactions: JRA and S-Bigbottom
#28
Basically your running 2x 4 ohm cabs.

Total load is 2 ohms

As long as your amp can handle 2 ohm load and not shut down or overheat or crakle like a turd. your good

Even amps that are " designed" to handle 2 ohms. Dont mean that its a cake walk for them.

2 ohm load is a pain in the butt either way for a amp and will make alot of heat and stress the power supply.

lets say 8ohms and 4 ohms is a fairly healthy diet.

2 ohms is like a constant diet of pizza and chocolate cake. you can do that. just dont expect to live very long
