Count Bassie said:
Thanks, I need to do a little homework...
Click to expand...
This shows the basic difference using strat single coil pickups. (Tbird pickups have two coils connected in series within the pickup, but for now consider it as 1 coil with + and - out)

Usually on a Tbird PU, the - lead of the pickup coil is connected to the pickup case and the braid(shield).
If you want to connect the pickups in series, that - lead needs to be kept separate from the ground. That's why they changed the wire for one of the pickups to two conductors and a shield.

Hopefully this makes sense!

  • Like
Reactions: Nocturnal, Count Bassie, RedVee and 5 others
#321,309
Engle said:
This shows the basic difference using strat single coil pickups. (Tbird pickups have two coils connected in series within the pickup, but for now consider it as 1 coil with + and - out)
View attachment 7249869
Usually on a Tbird PU, the - lead of the pickup coil is connected to the pickup case and the braid(shield).
If you want to connect the pickups in series, that - lead needs to be kept separate from the ground. That's why they changed the wire for one of the pickups to two conductors and a shield.

Hopefully this makes sense!
Click to expand...
Thanks Irv, I think so, yeah.
So one p'up has the shield connected, hence two leads. The other pu'p has it as a separate wire, hence three leads...
