Double Bass 1/4" mounting jack

[Mandobassman]

I am looking to wire a mic to a string mounted 1/4" jack. Does anyone know where to get one of these jacks (without a pickup attached to it).



[oerk]

If you have basic DIY skills, you can copy this. Just get a normal closed 1/4" jack. Bend a sturdy piece of metal on both sides, so that the middle part is 1-2mm narrower than the string spacing, drill a 9 or 10mm hole, mount the jack into the hole.



[DMH2]

I am looking to wire a mic to a string mounted 1/4" jack. Does anyone know where to get one of these jacks (without a pickup attached to it).

http://www.allparts.com/Switchcraft-Nickel-End-Pin-Jack-p/EP-4161-001.htm



[Mandobassman]

Thanks DMH2, but I was actually looking more for the part that mounts to the strings. I have fabricated my own, but it's kind of crude. I was hoping to find one that I could just mount the jack to. Thanks for the help anyway.



[bassteban]

2 large-diameter washers, sandwiching two adjacent strings, screwed onto jack.

Pic:
Link Removed
Pardon the blur..



[Mandobassman]

Excellent idea. I like it!!! The photo reminds me of the other thing I want to do. Get a right angle 1/4" jack.



[bassteban]

STREAMLINED, baby.



[oerk]

2 large-diameter washers, sandwiching two adjacent strings, screwed onto jack.

Pic:
Link Removed
Pardon the blur..

Ooooh, I like this idea! Extremely simple and effective.

I'm trying this today, if I can find large enough washers.



[cultrvultr]

You can also use a fully enclosed barrel type jack. They sell metal ones everywhere. RS carries a plastic version that works fine too. Install perpendicular to the strings and zip tie. Works pretty well.
