Will rack ears be available for the
800+?
I'll be on the road quite a bit this year
No, but I posted some detailed instructions on making your own rack kit using a standard heavy duty rack shelf and hardware. I will see if I can find it, but maybe somebody else has the link?
Here's a copy of the text below:
Here's the rack shelf that will work with the feet and has adequate stiffness to hold up to the weight:
[Invalid or Expired Link Removed]
[Invalid or Expired Link Removed]
Now there is the possibility that somebody here can work with the following blank faceplate to come up with the proper dimensions:
[Invalid or Expired Link Removed]
[Invalid or Expired Link Removed]
The head will mount using the front and back side screw holes and angle brackets (I would make mine out of 3/4" x 3/4" x 1/16" aluminum angle all the way from front to back) attaching to the sides with 6-32 x 1/2" pan head phillips screws and up from the bottom using 6-32 x 1/2" flat head phillips, countersunk in the bottom and using Kep nuts (locking) from the top side. I recommend aligning the front of the amp so that the faceplate overhangs the front flange by 3/16". Please double-check the height of the feet work with the 3/4" aluminum angle, as I do not have a set of feet here to test with. You can not mount safely using the feet screw holes.
For those of you with more advanced metalworking skills and tools, you can take the 2U blank aluminum faceplate and cut out the necessary hole matching the amp's faceplate and the nose will extend through the faceplate. Be sure to radius the corners and it will look trick. You do not need this trim faceplate to have this turn out solid, but it sure finishes it off. The trim faceplate can mount using just the rack screws or you can drill 2 holes per side and screw to the rack flange with 6-32 screws. Note that the shelf flanges are not all that rigid until you mount into a rack, so make your measurements on the trim plate, drill and transfer as needed. You may need to use a very short screw and will have to tap the sides, or possibly use just a couple of screws to mount to the bottom flange of the shelf, then the rack screws will finish it up.
Note that this shelf is deeper than the amp, but the flanges (returns) on the front and back of the shelf bottom are necessary for stiffness.
