The Acoustic Club

#6,201
iriegnome said:
The whole idea behind me picking it up was it was my very first amp. All options are very good, I will probably continue looking to find a picture of my original amp to verify that it was indeed a 126. Then I will start my search for it. Took me about 10 years to pull the trigger on the 136, so I am pretty patient.
Click to expand...

I've got a 126 I might list for sale. Sounds great. The output seems a little low to me, but I'm half deaf from my time in the army .

Last edited:
  • Like
Reactions: Rocker47, iriegnome, Stugilliam and 1 other person
#6,203
Syncopation said:
The seller says two of the E.Q. sliders don't work. Is this fixable?
Click to expand...

Impossible to say for sure, but most often a dead EQ slider usually means a problem with the inductor (coil) for that frequency. If you're lucky then resoldering the inductor's two leads might fix a cracked solder joint, but if the inductor has failed internally there's no easy fix since they're unobtanium.

The only other common problem is when the slider pots have been damaged from a sharp blow from the front and the phenolic wafer has been pushed out the back of the slider shell. If that's the case then you'll have to find another slide pot, a difficult but not impossible task.

  • Like
Reactions: Stugilliam and Syncopation
#6,204
JacklegBass said:
Impossible to say for sure, but most often a dead EQ slider usually means a problem with the inductor (coil) for that frequency. If you're lucky then resoldering the inductor's two leads might fix a cracked solder joint, but if the inductor has failed internally there's no easy fix since they're unobtanium.

The only other common problem is when the slider pots have been damaged from a sharp blow from the front and the phenolic wafer has been pushed out the back of the slider shell. If that's the case then you'll have to find another slide pot, a difficult but not impossible task.
Click to expand...
I do actually have a 126 amp of this generation that I could cannibelize for parts. I think the pre amps were all very similar. Could that work, maybe??

  • Like
Reactions: DJ Bebop and Stugilliam
#6,205
Syncopation said:
I do actually have a 126 amp of this generation that I could cannibelize for parts. I think the pre amps were all very similar. Could that work, maybe??
Click to expand...

Evidently the 126 & 320 used different EQ boards -- too bad, that would be the easiest thing to swap. But you're in luck! They both used the same five inductors, so you should be able to transplant just the two coils if you do end up needing them.

  • Like
Reactions: Syncopation, DJ Bebop, Stugilliam and 1 other person
#6,206
I should add, there should be a part number etched into the EQ's PC board. The 320's EQ board part number should be 170084B. The original 126 EQ board was part number 170076, but since I've recently become aware of a 2nd version of the 126 it's probably worth looking to see if your 126 has an '84B EQ board. If it did I'd swap the whole board rather than screwing around with individual inductors.

  • Like
Reactions: Syncopation, Stugilliam and DJ Bebop
#6,208
JacklegBass said:
I should add, there should be a part number etched into the EQ's PC board. The 320's EQ board part number should be 170084B. The original 126 EQ board was part number 170076, but since I've recently become aware of a 2nd version of the 126 it's probably worth looking to see if your 126 has an '84B EQ board. If it did I'd swap the whole board rather than screwing around with individual inductors.
Click to expand...
I would like to take this opportunity to thank, not just on my behalf, but I'm sure the other members of the A.C.C. club, For @JacklegBass immense knowledge and willingness to help others. Over the years I've had a multitude of questions, and Jackleg has always come through with the goods.
This is something I do not take for granted!
Thank you Sir!

  • Like
Reactions: rhythmwiz, KlankTank, jj4001 and 5 others
#6,209
Syncopation said:
I would like to take this opportunity to thank, not just on my behalf, but I'm sure the other members of the A.C.C. club, For @JacklegBass immense knowledge and willingness to help others. Over the years I've had a multitude of questions, and Jackleg has always come through with the goods.
This is something I do not take for granted!
Thank you Sir!
Click to expand...
+1!

  • Like
Reactions: Syncopation
#6,213
Syncopation said:
I would like to take this opportunity to thank, not just on my behalf, but I'm sure the other members of the A.C.C. club, For @JacklegBass immense knowledge and willingness to help others. Over the years I've had a multitude of questions, and Jackleg has always come through with the goods.
This is something I do not take for granted!
Thank you Sir!
Click to expand...
+4
It may be unofficial, but Jackleg you are considered an authority around here.

  • Like
Reactions: Stugilliam, StereoPlayer and Syncopation
#6,219
StereoPlayer said:
This is probably a re-hash of information but I ran across this article today.
https://www.newcutstudios.co.uk/a-big-acoustic-tower
Click to expand...
Maybe it's been shown here before but it's still a great article and there isn't one person, on this forum especially, who can say,Gee I didn't know that!! So, Thank You, for bringing this article to our attention, and I hope that you and the rest of the TB family have a Great and Healthy New Year!!

  • Like
Reactions: Syncopation and StereoPlayer
#6,220
  • Like
Reactions: Rocker47, lug, yakmastermax and 4 others
