Hot off the presses - hear the effect of a whole bunch of identical pickup coil placement and combination variations. 15, to be exact. With quick nav links! I'm fascinated by comb filtering and how dramatically it affects tone when you combine 2 or more coils, and placement has just as large an effect. Anyway, the YouTube blurb is below:
15 variations shown! 4 identical pickup coils in different locations, all just a little more than one inch apart. That inch can make a massive difference and impact! And when you combine multiple coils (up to all 4 here), you can hear very clear changes in tone that can sound a lot like some of the more archetypical basses and guitars out there - such as the Fender Jazz Bass, Strat, P-bass, Telecaster, StingRay, Warwick Thumb & Dolphin & others.
The architecture / design of these pickups has a large impact as well; large diameter, single pole pieces centered under each string vs bar magnets, offset pairs, etc.
All coil combinations made here are PARALLEL. Series wiring offers even more tonal options.
Quick navigation links:
0:00 Neck pickup, neck coil solo (Precision Bass like)
0:18 Neck pickup, bridge coil solo
0:37 Bridge pickup, neck coil solo
0:56 Bridge pickup, bridge coil solo
1:14 Neck pickup, both coils
1:34 Beck pickup, bridge coil; Bridge pickup, neck coil (Musicman StingRay)
1:54 Bridge pickup, both coils
2:11 Neck pickup, neck coil; bridge pickup, neck coil
2:29 Neck pickup, neck coil; bridge pickup, bridge coil (J-Bass)
2:50 Neck pickup, bridge coil; bridge pickup, bridge coil (Thumb Bass)
3:11 Neck pickup, both; bridge pickup, neck coil
3:31 &
4:48 Neck pickup, both; bridge pickup, bridge coil
3:50 Neck pickup, both; bridge pickup, both
4:10 Neck pickup, neck coil; bridge pickup, both (Warwick Dolphin, Lakland)
4:31 Neck pickup, bridge coil; bridge pickup, both
