The Sushi Box FX Secret Society

#20,741
That speckled finish on the Neptunium is gorgeous. Can't wait!

smeet said:
Oh and a companion question - I know it doesn't have a DI, but other than that how does the More compare with the Finally?
Click to expand...

The More is actually a great companion to the Finally. It will bring in more low end and round off some treble. I tested this combo yesterday and it tracked very well with my PJ. Gave that really sweet and warm sound.

lomo said:
A tale of tube rolling.......
Click to expand...

Speaking of tube rolling, I started just for fun and the experience but one I rolled started me down a rabbit hole. I read the Sovtek 12AX7WB had a dark sound, so I gave it a shot in my Underground Accelerator. Started it up and it barely made any sound, so I figured it might need more voltage. Fed it 12V and it started working fine. And for those wondering, the Sovtek 12AX7WB sounds amazing for a fat overdrive/distortion in the UA!

But that lead me to test bumping the voltage on my Finally and Nobelium, and found something interesting. Giving those 12V seems to enhance the sound, as in everything is more clear and present. To my ears running the stock 9V is like having a cab sim on, and 12V the cab sim is off. This has been the same for all the tube varieties I've tried, with the Sovtek the only one that required 12V to operate properly. @Sushi Box FX can you give some details on what's happening with 9V vs. 12V, and if there's anything to look out for regarding tube voltage?

#20,742
Sushi Box FX said:
Got together the first production-version unit put together this afternoon and snapped some pics of this handsome thing. I think this covers everything, let me know if there are other specs anyone wants to see.

Specs:
  • Input impedance: 10MΩ
  • Input: unbalanced 1/4"
  • Outputs: unbalanced 1/4" preamp out; balanced XLR preamp out
  • Power input: 9-12VDC
  • Current draw: 470mA at 12V; 390mA at 9V
  • Tube: 12AU7
  • Tonestack: Fender-style shelving with fixed mids control; neither control has a fixed center frequency, they are interactive and shift as the controls sweep
  • D.I. transformer: Unagi E4305
  • Signal capacitors: metallized polyester film
  • Signal resistors: thick metal film
  • Enclosure size: 4.8"x2.6"x1.6" (122mmx66mmx39.5mm)
  • Unit weight: 12oz (340g)
  • Price: $350 USD
View attachment 5489714 View attachment 5489715 View attachment 5489716
Click to expand...

Priced correctly for what you're getting. Definitely going to order one.

  • Like
Reactions: Sushi Box FX and Rickplaysbass
#20,743
Sushi Box FX said:
Thanks :) I've been building for a while and I've come a long way, I'm very proud of the way this all fits together. I had been wanting to do something like this for a while, so I spent a lot of time trying to maximize the usable space inside the box in order to make it fit the way I want it to.
Click to expand...
Amazing work! Congrats… So when do these go on sale? :-)

  • Like
Reactions: Sushi Box FX and Rickplaysbass
#20,745
  • Like
Reactions: chiphaleonbass, Sushi Box FX, warptheory and 3 others
#20,747
Rickplaysbass said:
I bet this guy smacks at Tetris. Probably loads the hell out of a trailer too.
Click to expand...
I can definitely hold my own at tetris, and I can load the hell out of a trailer.

Feral said:
@Sushi Box FX can you give some details on what's happening with 9V vs. 12V, and if there's anything to look out for regarding tube voltage?
Click to expand...
The high voltage generated inside all of my pedals is regulated, which means it measures its own voltage and adjusts it as necessary to keep it at the value it's designed to be at, and that value is independent of input. So anywhere from about 6V to 18V would give you the same high voltage to the tube plates. The only other thing seeing that voltage is the tube heater. Per the datasheet the heater needs 12.6V when running it in series like I do, and it's common to run it at 12V since we can get that on our boards pretty easily these days, but there have been loads of historical precedence for running a heater at 9V instead. There is no audible difference (to me at least, I've met a few people that swear they hear it), but it runs the heater a little cooler which means less current draw and at least a small increase in lifespan of the tube.

letsgethandsome said:
Amazing work! Congrats… So when do these go on sale? :)
Click to expand...
I just finished up the last of the WBIM Finally preorder builds, now I have a couple repairs that have been waiting for me for a few days, then after that we get to see how fast I can built Neptuniums. The answer is of course probably faster than you think but not as fast as I would like, which should land us around early July.

Also as I was finishing up the last Finally builds I realized my Neptunium build doesn't have the Unagi Magnetics sticker, I am planning to stick those on.

  • Like
Reactions: WRM, Rev_Slinky, squeally dan and 8 others
#20,750
I assume the production process requires some care... I hope you are having enough sleep to handle all that!


  • Like
Reactions: WRM, Maxi Funkl, wayshot and 3 others
#20,751
Sushi Box FX said:
Got the first production-version unit put together this afternoon and snapped some pics of this handsome thing. I think this covers everything, let me know if there are other specs anyone wants to see.

Specs:
  • Input impedance: 10MΩ
  • Input: unbalanced 1/4"
  • Outputs: unbalanced 1/4" preamp out; balanced XLR preamp out
  • Power input: 9-12VDC
  • Current draw: 470mA at 12V; 390mA at 9V
  • Tube: 12AU7
  • Tonestack: Fender-style shelving with fixed mids control; neither control has a fixed center frequency, they are interactive and shift as the controls sweep
  • D.I. transformer: Unagi E4305
  • Signal capacitors: metallized polyester film
  • Signal resistors: thick metal film
  • Enclosure size: 4.8"x2.6"x1.6" (122mmx66mmx39.5mm)
  • Unit weight: 12oz (340g)
  • Price: $350 USD
View attachment 5489714 View attachment 5489715 View attachment 5489716
Click to expand...

Will Neptunium feature the switch to bypass (passive DI) discussed in your post No. 20376?

What does the switch on the left side do?

Thank you.

  • Like
Reactions: Parzival
#20,753
Sushi Box FX said:
Got the first production-version unit put together this afternoon and snapped some pics of this handsome thing. I think this covers everything, let me know if there are other specs anyone wants to see.

Specs:
  • Input impedance: 10MΩ
  • Input: unbalanced 1/4"
  • Outputs: unbalanced 1/4" preamp out; balanced XLR preamp out
  • Power input: 9-12VDC
  • Current draw: 470mA at 12V; 390mA at 9V
  • Tube: 12AU7
  • Tonestack: Fender-style shelving with fixed mids control; neither control has a fixed center frequency, they are interactive and shift as the controls sweep
  • D.I. transformer: Unagi E4305
  • Signal capacitors: metallized polyester film
  • Signal resistors: thick metal film
  • Enclosure size: 4.8"x2.6"x1.6" (122mmx66mmx39.5mm)
  • Unit weight: 12oz (340g)
  • Price: $350 USD
View attachment 5489714 View attachment 5489715 View attachment 5489716
Click to expand...

That looks awesome! Congrats @Sushi Box FX
Those should sell out FAST

  • Like
Reactions: Sushi Box FX
#20,754
OldShark said:
Wow, that Neptunium is tightly packed... Will ordinary folks be able to roll tubes?

Can you tell about the HPF specs, please?
Click to expand...
The tube has exactly the same amount of room as Finally. You can get in there no problem if you have little fingers like me, but as noted above removing the input jack will open up space and make it easier.

The HPF has the same spec as the Noble and Nobelium, -6dB per octave below 90Hz. Apparently it's too late for me to edit the above post to add this, but that absolutely should have been in there.

Zbysek said:
Will Neptunium feature the switch to bypass (passive DI) discussed in your post No. 20376?

What does the switch on the left side do?

Thank you.
Click to expand...
No, the passive DI switch referenced in post 20376 is only available on Venus Z as there just isn't any room for it on the smaller builds like Finally or Neptunium.

The switch on the left side is a ground lift for the XLR output.

  • Like
Reactions: WRM, Rev_Slinky, FourStringMF and 4 others
#20,757
Sushi Box FX said:
Got the first production-version unit put together this afternoon and snapped some pics of this handsome thing. I think this covers everything, let me know if there are other specs anyone wants to see.

Specs:
  • Input impedance: 10MΩ
  • Input: unbalanced 1/4"
  • Outputs: unbalanced 1/4" preamp out; balanced XLR preamp out
  • Power input: 9-12VDC
  • Current draw: 470mA at 12V; 390mA at 9V
  • Tube: 12AU7
  • Tonestack: Fender-style shelving with fixed mids control; neither control has a fixed center frequency, they are interactive and shift as the controls sweep
  • D.I. transformer: Unagi E4305
  • Signal capacitors: metallized polyester film
  • Signal resistors: thick metal film
  • Enclosure size: 4.8"x2.6"x1.6" (122mmx66mmx39.5mm)
  • Unit weight: 12oz (340g)
  • Price: $350 USD
View attachment 5489714 View attachment 5489715 View attachment 5489716
Click to expand...

Nathan That Looks Glorious!! I may have missed it, but what's that nifty little side switch and the black knob do???

  • Like
Reactions: Kubicki Fan and Sushi Box FX
