Got the Combustion 4 with 2 pickups a week ago from my local music store. Was planning to get the D-Rock but after playing it a bit it became clear that neck is very different from the one I got used to (MusicMan Stingray/Reflex), so different that my left wrist started to hurt after 10 min of playing...
Anyway, I'm pretty happy with the new bass, but my thumb is terribly missing the MM bridge pickup (makes an awesome thumb rest). So I'm thinking about putting 3rd (middle pick-up) into it in hope to have the thumb rest and more tones. There are more that 2000 pages here, i.e. all this was probably already discussed (several times) - will appreciate if somebody throw me a link related to adding 3rd pickup and changing the rotary selector.
You can reach out to a Dingwall dealer or Dingwall themselves for pricing. It was $200 Canadian last I checked, they give you a third pickup, a new pickguard, and a new 6-way rotary which is built for their 3 pickup configuration. On your combustion it should change the Bridge/Neck Series setting to be Bridge/Middle series and everything else would be the same.
On my lovely Z2 I still haven't been able to figure out the combinations for the controls.
Yes, I found the schematics (which interestingly aren't included at
Z2 Pickup & Control - mine has three toggle switches for s/p neck, s/p bridge, and 220/500Hz mid freq).
What I am missing is an "Idiots guide to tones" for a Dingwall Z2 with FD-3 & Glockenklang 3-band EQ.
I hear people talk about "getting a P sound" or a "J sound" or... references to other bases like MM... but what does that mean? How do I get these sounds, when would I want those?
Sure, one answer is "play around and use what you like", but I wonder if there is a more structured writeup somewhere...
Usually it's because the "sound" of a type of bass often has to do with the pickup placement and wiring. A P-bass is a split-coil closer to the neck in series for boosted low mids. A jazz bass is a bridge and neck pickup wired in parallel to blend between. A musicman is a bridge humbucker usually wired in parallel but sometimes switchable to series.
So when thinking about a 3x dingwall with 3 pickups in a row, you can cop some of those combinations.
Bridge solo, Middle solo, and Neck solo are just pickup sounds at those positions. Not unlike a Jazz with pickups there. But their pickups are all split coils too, so you can go series/parallel inside the pickup. Neck only or middle only in series might get you more like your P bass tone.
Neck and Bridge in parallel is like your Jazz configuration, since that's what the blend sound of a J-bass is like.
Bridge and middle in parallel is closer to the two parallel coils of a Musicman, and series is more like a MM pickup in series (purely based on placement and wiring).
And if you have series/parallel switches on all three pickups you can vary those too.
But so basically:
Bridge/Neck parallel - Jazz bass pickup arrangement
Bridge middle parallel/series - MM pickup arrangement (usually parallel, but some were switchable.
Then the individual pickups might have placements similar to other basses, like Jazz Bridge or neck for bridge or neck, P-bass placement is somewhere in there. Middle might be like the neck on a warwick thumb, etc.
