GK rails in a pedal?

#681
johnk_10 said:
IMO, it can be used as a subtle overdrive or a nearly clean boost.
Click to expand...
I'd agree with that. In my (very) limited tests so far, I actually prefer it relatively subtle. Input at about 1/3, output at unity. We'll see how it is in my mix, since this will be my "fuzz" pedal, but I'm expecting good things. I'll be giving in a good run through at volume here in a few hours. Before then, what exactly does the Hi-Cut switch do? I couldn't really tell any difference except one setting (middle I think) made my cab hiss a bit. Again, I'll test at volume and see if I can hear a difference, but I typically don't like tons of treble, so will probably want it "off", whichever setting that is.

#683
johnk_10 said:
the high cut filter's freq response is posted earlier in this thread.
Click to expand...
I've read the charts, but I'm needing to know which setting of the switch is which. In other words, is "up" a big treble boost, center a "little" boost, and down "off", or what have you? I can't tell what the switch does for the sound in my use so far. Except from the aforementioned hiss, all three switch settings have sounded identical. Sorry if I'm not being clear (or don't understand when I've read through this material and it's over my head to comprehend).

#685
kleinenenten said:
I've read the charts, but I'm needing to know which setting of the switch is which. In other words, is "up" a big treble boost, center a "little" boost, and down "off", or what have you? I can't tell what the switch does for the sound in my use so far. Except from the aforementioned hiss, all three switch settings have sounded identical. Sorry if I'm not being clear (or don't understand when I've read through this material and it's over my head to comprehend).
Click to expand...

There is no HF boost in this design. The HF cut switch is off (center pos) or the two HF cut frequencies. You will need to ask the builder of the pedal what HF cut frequency is used for the other switch positions (because the switch can be wired either way).

John beat me to the post button.:)

-Frank

#686
johnk_10 said:
there's no high boost setting at all. center is no high cut (i.e flat). I don't know how domidec's version is , but on mine, up is a mild high cut, and down is more high cut.
Click to expand...
Sorry, wrong word! Thanks for the info, and I didn't even think to ask domdec if his is different! I figured you're using the same schematics and all, but I'll ask him and post the results here in case anyone else needs/wants the info. Thanks as always!

#690
nshuman said:
I will let you know how it sounds through tubes when I get mine :)
Click to expand...
and yours is shipping tomorrow. :thumbsup:


  • Like
Reactions: El Spearo, Veldar, willbassyeah and 9 others
#692
Ok, to put it to rest, here's the result of my switch question: Up cuts a lot, down cuts a little, middle is flat. It had a pretty good impact on the sound (once I was at volume). At lower settings, it isn't prominent. So far, I prefer it at one of the cut options. I'll have to test it in the mix to decide for sure. It sounds great at pretty much any setting, but at lower gain settings you might need to engage the boost to really hear the distortion sounds. Either way, it's a great pedal and goes from nearly clean to raunchy. Should definitely take my fuzz's place, as was the intent. Works well with other effects as well. Specifically, I tried it with envelope filter, flanger and phaser.

In short - great pedal! Don't see mine going anywhere anytime soon!
