My entire signal chain explained in written form :
(*pedals listed in [ red/bold/underline text ] are "always on" effects*)
4 string 28,6" scale Ibanez GSRM20 neck + GSRM20B body Mikro Bass (equipped with an EMG Geezer Butler P pickup, wired directly to the output jack socket, and strung with gauge .95 - .75 - .55 - .40 D'Addario XL nickle roundwound steel core strings, tuned in F# standard tuning, 2 half steps above regular 4 string bass E standard tuning) ->>
TC Electronic SpectraComp (always on compressor) ->> TC Electronic Sub'N'Up Mini (always on digital polyphonic octaver, used as an 1 octave up effect mixed with clean bass signal, giving an effect similar to that of an 8 string "octave" bass, with pairs of respectively bass and octave strings) ->> Boss LS-2 [A+B Mix <-> Bypass] (always on, parallel effect loops mixer/switch) ={ [Loop A Send] ->> Joyo Orange Juice (always on low gain overdrive, really primarily used to enhance harmonic content, [Tone] set at about 11 o'clock, [Voice] set to boost a wide curve around a 800Hz center frequency about +3dB pre gain stage, always mixed with clean {bass+octave up} signal from parallel effects [Loop B]) ->> [Loop A Return] ->||<- [Loop B Send] ->> (empty effects loop for clean {bass+octave up} signal blend with Orange Juice in effects [Loop A]) ->> [Loop B Return] ([Loop A] + [Loop B] mixed at an about 55/45 ratio) }=>> Boss LS-2 [A+B Mix <-> Bypass] (parallel effect loops mixer/switch) ={ [Loop A Send] Behringer SF300 Super Fuzz (Boss FZ-2/Univox Super Fuzz clone, octave fuzz, always mixed with clean {bass+octave up} signal from parallel effects [Loop B]) ->> Joyo Orange Juice (lower medium gain grindy kind of overdrive, always used stacked into the Metal Zone in front of it, and always mixed with the Rat distortion in parallel effects [Loop B]) ->> Boss MT-2 Metal Zone (distortion, used with a relatively low gain setting, and always used with the Orange Juice behind it stacked into it, and always used mixed with the Rat distortion in parallel effects [Loop B]) ->> Behringer VP1 Vintage Phaser (EHX Small Stone clone, used in the high feedback and deep sweep mode, always used boosted by the Hotone Trem in front of it, and almost always used mixed with flanger in parallel effects [Loop B]) ->> Hotone Trem (Tremolo with rate and depth at 0, always used to boost either the Behringer phaser placed behind it and make it a bit brighter, since it's a few dB above unity gain when engaged and got a tone control) ->> [Loop A Return] ->||<- [Loop B Send] ->> Mosky Black Rat (RAT clone, in original classic RAT [Vintage] mode, quite raunchy, fuzz-esque, high gain distortion, always used mixed with the Metal Zone distortion in parallel effects [Loop A]) ->> Monarch MFL-22 (flanger, most often used mixed with phaser in parallel effects [Loop A]) ->> [Loop B Return] ([Loop A] + [Loop B] mixed at an about 50/50 ratio) }=>> Artec SE-EQ8 Graphic EQ (always on 8 band graphic equalizer: [100Hz LoShlv= +1dB ; 170Hz (low Q)= 0 ; 280Hz (high Q)= +3dB ; 500Hz (high Q)= 0 ; 800Hz (high Q)= +1dB ; 1.4kHz (high Q)= +3dB ; 2.3 (low Q)= +3dB ; 5kHz HiShlv= -10dB]) ->> Zoom G1Xon (Used for an always on 2 band parametric equalizer [Freq=63Hz Q=4 Boost=+1dB ; [I]Freq=200 Q=2 Boost=+1dB], and additionally used for 3 patches (all including the EQ at the end of the chain), which respectively are as follows: Tremolo+VintageCE (Boss CE-1 emulation), chorus patch :-: Plate Reverb+HD Hall Reverb+Tape Delay, prominent reverb patch :-: Plate Reverb+HD Hall Reverb+Tape Delay, extremely thick lush reverb patch, used as a reverb pad effect with volume swells) [/I]->> NUX Tape Core Deluxe (Roland Space Echo tape delay emulation) ->> Zoom MS-70CDR (always on 2 band parametric EQ [Freq=400Hz Q=2 Boost=+1dB ; [I]Freq=1kHz Q=4 Boost=+1dB], subtle plate reverb, and faux, EQ based, cab sim, consisting of a 2 band parametric EQ set as follows: [Freq=12kHz Q=1 Cut=-18dB ; [I]Freq=20kHz Q=0.5 Cut=-20dB], plus a lush Church Reverb model with a line selector behind, making it switchable on/off)[/I][/I]
->> Band rehearsal/jamming/gigging // ->> Home practice / Home recordings :
->> EHX Black Finger (always on tube driven optical compressor, dialed in to a quite subtle compression, primarily functioning as a tube preamp stage) ->> Art Tube MP Project Series (tube preamp, with HPF at 40Hz) // ->> Band rehearsal/jamming/gigging ->> [Effects Return] (poweramp input) of Peavey Solo Special 112 (160W, solid state guitar combo, with the build in 4 Ohm 12" speaker unit disconnected and instead hooked up to a The Box PA 502 PA speaker) ->> The Box PA 502 (full range PA speaker with 1x 15" + 1.7" high frequency tweeter horn) // ->> Home practice / Home recordings ->> Behringer Eurorack UB1202 (mixer) ->> [ ->> Sennheiser HD 380 Pro (headphones) ]/[ ->> Behringer Tube Ultragain MIC100 (tube preamp) ->> M-Audio Fast Track (sound interface) ->> Reaper (DAW) ]
That adds up to 17 pedals, 18 if you count the Art preamp, and 8/9 always on.
