I was a little puzzled by the control arrangement on the H1. So I popped an email over to their support people and got this very helpful reply back. Figured I’d share it here so Huntington I owners (or people who are contemplating getting one) know what’s up with this particular model. Because it’s different from anything else I’ve ever run into:
————
“Hi Ed,
Just to clarify a bit further on Kenny's comments:
We've set the piezo up in a way that is very interesting; something I've not seen any other manufacturer do.
When in the 'bridge' position, (that is, piezo active), the tone capacitor is dropped from the circuit, and the piezo is inserted on the other leg of the tone pot. This allows the tone pot to now act as a blend between mag-only, and mag-piezo (with the pot rolled all the way up, it's a bit more than a 50-50 mix, more piezo than mag; conversely, rolled all the way down, you still get just a bit of piezo in the mix)
On the practical side, one way to think of this is like having a "dual-range" tone pot. In the mag only setting, the tone pot acts just as you would expect, removing highs as you roll it down. In the piezo position, the tone pot starts where the mag-only setting ends. Thus, with the tone pot rolled off, you have the tone of the mag p/u, with full highs. As you roll the tone knob up, you're increasing the amount of piezo, and as piezo's are rather bright, you are increasing the highs in your tone, along with all the super-fast transient response that piezo's have.
Now, since the piezo is connected directly to the output, bypassing the vol pot, if you roll down the volume, you are only affecting the mag p/u. In this way you can get the piezo solo, with the tone pot now acting as the piezo volume.
In my rig, I've found that I really like the tone of the mag p/u with the tone rolled back 1/3-1/2 way. When I switch to piezo+mag, I get a little bump in volume, and a good bit more 'grind', which my OD pedals really seem to like. Great for that smooth verse, heavy chorus transition!
Hope this is helpful! Hit us up if you have any other questions.
Best,
David Buchter”
————
Pretty interesting huh?
