Thanks. I'll try something along those lines for sure, I have two K4s and one K1 installed, the latter in the E-sided foot of the bridge as per the original instructions, so much less proximity to the strings than the K4 anyway, but I'll still try that first. Any hunch on where you would point that single module, if it's drilled into the bridge arc?
Enjoy the benefits of a premium membership!
Upgrade Account
-
TalkBass has been independent since 1998. Add your voice.
Create a free account to reply to discussions, view embedded media, and browse with fewer display ads.
Join free Log in
Want zero display ads or expanded classifieds tools? Compare plans.
Double Bass Wilson K4
- Thread starter flatback
- Start date
I think having just one opposite the E bridge wing is dope. Twisting it gets lots of different sounds.
Earl
Supporting Member
This is similar to the Bassbalsereit pickup that I have. Same location, and turning it produces a wide variety of sounds (a few you would never want to use!)
Video link
https://youtube.com/shorts/2ddoodVNhtQ?feature=share
bit with the sound of a K2 (2 pickups set back from the strings way more then the directions, other 2 pickups dangling) thru a Felix and MAS18 in a very unforgiving room.
https://youtube.com/shorts/2ddoodVNhtQ?feature=share
bit with the sound of a K2 (2 pickups set back from the strings way more then the directions, other 2 pickups dangling) thru a Felix and MAS18 in a very unforgiving room.
I useing Wilson K1 for about 5+yrs..
It’s the best pickup what I ever used (BP-100, FC, Ehrlund, Realist). I tired k4 on a rental bass while touring, but I preafer K1, more body, better phase coherency, and cheaper….
It’s the best pickup what I ever used (BP-100, FC, Ehrlund, Realist). I tired k4 on a rental bass while touring, but I preafer K1, more body, better phase coherency, and cheaper….
So there is clear difference with the pickup mounted from the front or the back? If I decide to try a K1 by the E string wing, should I have the hole drilled all the way through?
AFAIK the bore and pickup element is slightly conical to be able to vary the pressure on the pickup when mounting it. So you must decide before the holes are drilled (or at least are reamed afterwards) on which side of the bridge the pickup element should enter the hole.
FWIW I futzed around with it and listening on headphones. I get very little bass power on my Low C string (I tune in 5ths - so it's the same as E string in 4ths) unless the pickup is mounted in the leg. I played around with the two positions with the other element and I still prefer it on the bass side. It's a little more woody and blends better with the element in the bass leg.
Again, this is on my old Yamaha SLB200 EUB and it to me, it makes it a serious instrument that could compete with full bodied basses. I am not a pro but i could totally see someone touring with this setup. Pop the EUB folded up in a golf club case and you're off to the races.
Again, this is on my old Yamaha SLB200 EUB and it to me, it makes it a serious instrument that could compete with full bodied basses. I am not a pro but i could totally see someone touring with this setup. Pop the EUB folded up in a golf club case and you're off to the races.
That sounds wild!@flatback Or, you could get a second Felix, have both modded with variable phase controls, and have a separate volume, tone, and phase control for each string!(Didn't NHØP have something akin to the 70's version of that in his briefcase?)
I was doing this with a small mixer blending an Underwood with a Pierre Joseph String Charger. I would also run the String Charger through my Zoom B1xon for some trippy hippie upright stuff
FWIW I switched my K2 to be top treble spot with the other in the bass leg. I wasn't getting enough signal for the bow in the higher register on my high strings. Now it's all ballsy. I actually I think I like this better in hindsight. If I turn up the gain and overdrive my amp a little bit, I'm learning to enjoy a little bit of grit in my signal with the Yammy. It's not all delicate and arco sounds real nasal. But pizz is lots of fun. Still does'nt sound like an EUB yet it doesn't have the air of a DB. Sounds like a throwback to the 80s sound where most of everything is coming from the pickup.
Hi, I just installed the Wilson K4 on my bass, but I have a small problem. I’m getting a persistent buzz that stops whenever I touch one of the pickups. It seems to be a grounding issue, similar to what you can get on an electric guitar. Has anyone experienced the same problem and figured out how to solve it?
I tested the pickup before mounting it on the bass and didn’t notice anything unusual.
I tested the pickup before mounting it on the bass and didn’t notice anything unusual.
Earl
Supporting Member
Yes, I tried other cable and other amp. The amp is plugged into a grounded outlet.
After couple of tests I noticed than when plugging in another room the problem was still there but lighter.
The pickup seems to be very affected by the electric signal.
I contacted Wilson and they suggested try to connect the 'shield-part' of the jack, to one or all four strings, simply by inserting a small wire between those parts.
I'll post more after trying this option.
After couple of tests I noticed than when plugging in another room the problem was still there but lighter.
The pickup seems to be very affected by the electric signal.
I contacted Wilson and they suggested try to connect the 'shield-part' of the jack, to one or all four strings, simply by inserting a small wire between those parts.
I'll post more after trying this option.
