Guys, here it is. I can't believe it fit! That wasn't even my original plan.
Chain:
Bass/guitar -->
Digitech Drop -->
Source Audio Manta Bass Filter -->
Empress Compressor -->
Loopmaster True Bypass Looper -->
(Behringer BSY600 -->
Digitech Bass Synth Wah) -->
Empress Heavy -->
Empress Multidrive -->
Eventide Pitchfactor -->
Eventide Modfactor -->
Line6 M5 -->
Darkglass B7K -->
Pigtronix Infinity Looper -->
Singular Sound Beat Buddy -->
Amp
Controllers:
Source Audio HH3 --> Source Audio Manta
Digitech FS3X (#1) --> Eventide Pitchfactor
Digitech FS3X (#2) --> Eventide Modfactor
Ernie Ball VP Jr. 25k --> Eventide Modfactor
Source Audio HH3 --> Line6 M5
Custom Dual Momentary Switch --> Pigtronix Infinity Looper
this1smyne 25k Stereo Expression Knob --> Pigtronix Infinity Looper
Singular Sound Beat Buddy Footswitch --> Singular Sound Beat Buddy
MIDI Chains:
#1: Eventide Modfactor --> Eventide Pitchfactor --> Line6 M5 (tap tempo throughout, expression CC from Modfactor to Pitchfactor)
#2: Singular Sound Beat Buddy --> Pigtronix Infinity Looper (tempo, start, stop)
Power:
Voodoo Labs Pedal Power Mondo (including multiple pedals on the courtesy outlet for now)
Cables:
All signal chain cabling between pedals is with EBS Flat Cables. TS/TRS cabling for controllers is a mix of different things.
The underneath is a bit of a bird's nest, and I need to figure out the power. I may or may not be able to get by with what I have, but I will have to add some daisy chains/current doubling cables/voltage double cables. I took off the Morpheus Droptune and Source Audio Dual Expression Pedal (on the block soon) to do this. The Ernie Ball VP Jr. might eventually be replaced by a Source Audio Reflex. The Beat Buddy extra footswitch is kind of unwieldy; I'm considering ditching it for another custom made 1590A-sized one---I found a guy on eBay who will do those kinds of things at very reasonable prices, I'm very happy with the one he made for my Infinity.
