Okay Doc, I guess I agree, kind of. But bear with me please. I acknowledge you are the master.
Functionally, that’s correct. When you are using the HPF, you are not getting an overall phase reversal. But ... that’s because the phase has been reversed twice, again as I understand it.
The master? Well, I don't know about that. Not being an owner of one of these amps and based on what has been posted here, I thought that the user was able to choose the notch filter, the high-pass filter, or both. I now understand that one can choose the notch OR the high-pass filter.
Still, what I said was correct. When you select the notch filter, the filtering circuitry that is implemented is one that reverses phase. When you select the high-pass filter, the circuit that is implemented does not reverse phase. That is the plain truth.
Now, I think I know from where the idea of reversing the reversal might have come. According to Rick, and as I suspected, the overall phase-reversal from the notch filter comes about because of the use of inverting op-amps and the particular circuit topology employed.
The notch filter employs an odd number of these inverting op amps while the high-pass filter employs an even number. Now, given the fact that the user can choose EITHER a notch
or a high-pass filter,
I suspect, but do not know, that the design is akin to something like the following:
The notch filter is created by combining a low-pass and a high pass filter with separate corner frequencies. For example, if you want a notch around 50 Hz, you might low-pass at 40 Hz and high-pass at 60 Hz. In this example, 50 Hz falls in the "stop-band" (the part rejected by the filter) of both the low-pass and high-pass filters. Thus, you end up with a notch in the 50-Hz region.
When you choose the high-pass filter, you are selecting only the high-pass section of the pair.
Now, suppose that there is what is called an inverting "buffer" op-amp sitting in front of the filter section. Well, that will flip the signal once. Now, suppose each filter, that is low-pass and high pass, is implemented with an odd number of op-amps. Let's say the number is three. When you select the notch filter (activating both the low-pass and high-pass filter circuits), the total number of inverting op-amps is odd. In our example, 3 (low-pass) + 3 (high-pass) +1 (buffer amp). Now, when you select the high pass filter, the total number of inverting op-amps is even. In our example, 3 (high-pass) +1 (buffer-amp). Now whenever the number of inversions is odd, the net effect is a phase reversal; when it is even, the net effect is no phase reversal.
Again, I do not know this is how the AI is designed but my example illustrates how the inversion and non-inversion could come about.
There is a schematic on their web site. Means nothin’ to me. But maybe others would like to pore over it.Wouldn’t it be nice?
I found the signal-flow diagram on the site that is within the manual. If you showed me a real schematic, I could be much more definitive.
