The Sushi Box FX Secret Society

#601
kranahan said:
Time to up your power game!
Click to expand...


Cioks DC7 FTW!

  • Like
Reactions: Lowendtech and kranahan
#602
kranahan said:
I know you've heard this in every other thread but... Just get a Cioks DC7 with a 4 or 8 and call it a day. You will never have to worry about power again.
Click to expand...
Yes....I know. It solves all of the world's problems, and even makes you a sandwich. I've got a Strymon Zuma - not exactly junk....powers 2 of my pedals at 18v and supplies 500ma to 9 outlets. Problem is mainly that the DC7 can't replace it by itself....as you said, I'd have to also get a 4. I still may end up going that route, but I'd be basically buying 2 new power supplies just to run one pedal that cost half as much as them. The Zuma has perfectly handled every other thing I've needed.

  • Like
Reactions: NKBassman and Zbysek
#608
kranahan said:
I was referring to Cioks adapters specifically. That's good to know they are that cheap though. Did you purchase one?
Click to expand...
Not yet, I did just order One Spot like power adapter from Amazon that will get here tomorrow just to be sure I can play with the pedal on Saturday....but yeah, if I find the 500ma doesn't cut it, I'll probably go ahead and go with a current doubler.

...and I actually have a y cable to power 2 pedals off of one outlet (was powering 10 pedals with my Zuma at one point)....so I could technically split that back out from the current doubler with a low power pedal. So I'd still get 2 pedals from 2 outlets....those 2 just wouldn't be isolated.

  • Like
Reactions: kranahan
#610
Eadger said:
Not yet, I did just order One Spot like power adapter from Amazon that will get here tomorrow just to be sure I can play with the pedal on Saturday....but yeah, if I find the 500ma doesn't cut it, I'll probably go ahead and go with a current doubler.

...and I actually have a y cable to power 2 pedals off of one outlet (was powering 10 pedals with my Zuma at one point)....so I could technically split that back out from the current doubler with a low power pedal. So I'd still get 2 pedals from 2 outlets....those 2 just wouldn't be isolated.
Click to expand...
You really are in quite the quandry!

#611
kranahan said:
Which one is it? All I'm finding is the 8800 that uses two ports.
Click to expand...
This (the 2200) CIOKS 2200 SERIES ADAPTER FLEX (WHITE) cable doubles the mA. (I’m using one for my LA-1A). The voltage is controlled by the switches of course.
The 8800 takes one outlet and turns it into 2 so effectively halving the potential mA depending on what you have plugged into each end.

Last edited:
#612
Lowendtech said:
This (the 2200) CIOKS 2200 SERIES ADAPTER FLEX (WHITE) cable doubles the mA. (I’m using one for my LA-1A). The voltage is controlled by the switches of course.
Click to expand...
Um....pretty sure that is a voltage doubler. @kranahan is correct - the 8800 doubles current. And I'm pretty sure it'd be physically impossible for a simple cable to double the current without using 2 ports....unless the cable has it's own solar array or something.

#613
Eadger said:
Um....pretty sure that is a voltage doubler. @kranahan is correct - the 8800 doubles current. And I'm pretty sure it'd be physically impossible for a simple cable to double the current without using 2 ports....unless the cable has it's own solar array or something.
Click to expand...
The 2200 uses 2 ports and has one outlet.

Edit: Both outlets are set to 12v/500mA. At the single outlet from the 2200, I have 12v/1000mA, which is what the LA-1A needs.

Last edited:
#614
Lowendtech said:
The 2200 uses 2 ports and had one outlet.
Click to expand...
Both the 2200 and 8800 have two male ends and one female end - format is the same. 2200 doubles voltage (so you can take 2 500ma 12v ports and get 1 500ma 24v port) - the 8800 doubles current (so you take 2 650ma 9v ports and get 1 1300ma 9v port). The 2200 wouldn't be able to power your LA-1A.

  • Like
Reactions: CATFISHMcC0Y and kranahan
#615
Eadger said:
Both the 2200 and 8800 have two male ends and one female end - format is the same. 2200 doubles voltage (so you can take 2 500ma 12v ports and get 1 500ma 24v port) - the 8800 doubles current (so you take 2 650ma 9v ports and get 1 1300ma 9v port). The 2200 wouldn't be able to power your LA-1A.
Click to expand...
See my edited post above. My LA-1A would be fried if you were correct.

#617
Lowendtech said:
The 2200 is series. The 8800 is parallel.
Click to expand...
Well, I guess you can debate all you want, but the CIOKS website says otherwise. I'm literally quoting their descriptions - wasn't trying to argue, just stating the actual written facts of the products.

Edit: you're actually right on which is series and parallel....just wrong on what that does (current vs. voltage). 2200 is indeed series - but running in series doubles voltage, not current.

Last edited:
#618
Eadger said:
Yes....I know. It solves all of the world's problems, and even makes you a sandwich. I've got a Strymon Zuma - not exactly junk....powers 2 of my pedals at 18v and supplies 500ma to 9 outlets. Problem is mainly that the DC7 can't replace it by itself....as you said, I'd have to also get a 4. I still may end up going that route, but I'd be basically buying 2 new power supplies just to run one pedal that cost half as much as them. The Zuma has perfectly handled every other thing I've needed.
Click to expand...
Or, you could keep the Zuma and just add a DC-4. The DC-4 will power two SushiBoxes, cause you know you won’t stop at just one.

  • Like
Reactions: kranahan and Eadger
