So many years ago the original BB circuit and pickup went out so I replaced it with a Seymour Duncan music man 3 band eq, and a Bartolini W4CBC. well last week I ordered the re-issue BB circuit from Aria and it arrived this past Wednesday. I took pictures of the before, during, and after. So bare with me its the first time i've posted something like this.
This is what it started as: 1986 Aria Pro II SB-1000
i've made a few mods, sperzel locking tuners, Bartolini P/U
Seymour Duncan music man 3 band eq
View attachment 1837874
Close up of the body
View attachment 1837875
Control Cavity covers
View attachment 1837876
Control layout up close
View attachment 1837877
Covers removed showing the Seymour Duncan Preamp which i wired to 18 volts
View attachment 1837878
My bass is now gutless
View attachment 1837879
New Aria BB circuit installed, i taped some of the wires together just to make it a little neater looking, it is wired to run on 18 volts, as you can see the batteries are under the circuit board
View attachment 1837880
Finally installed, this was kind of a pain for me because i had to figure out what wires from pickup went to the open lugs on the toggle switch but a few minutes on the phone with a tech helped me out a lot
View attachment 1837881
A cable plugged in to show the LED works, it is used for a battery life indicator, also the toggle functions as an active passive switch and Jazz bass knobs for the volume and tone controls and the original pointer knob for the 6 way selecter switch
View attachment 1837882
This bass sounds soooooo amazing now I'll post sound clips soon
